KZ-S4H22-90EYS-DFV KZ Valve by Banjo | S Series | Stainless Steel Electric Valve | 1-1/2" Port Size | 1-1/2" Female NPT, Bottom Load | Control Type: ON/OFF/ON

KZ-S4H22-90EYS-DFV KZ Valve by Banjo | S Series | Stainless Steel Electric Valve | 1-1/2" Port Size | 1-1/2" Female NPT, Bottom Load | Control Type: ON/OFF/ON

Minimum Order Quantity: 5 Units

Save $129.09 Save $129.09
$1,161.77
$1,161.77 - $1,161.77
$1,161.77
$1,032.68
$1,032.68 - $1,032.68
$1,032.68

Banjo® Liquid Handling Products
KZ Valve | S Series | Stainless Steel Electric Valve
Specifications for Variant SKU: KZ-S4H22-90EYS-DFV Banjo
Brand: KZ Valve
Series: S Series
Material(s): Stainless Steel
Materials:
  • Valve body: CF8M stainless steel
  • Ball: 316 stainless steel
  • Stem: 316 stainless steel
  • Seat: Carbon-graphite-filled PTFE or Virgin PTFE with VitonTM back-up O-rings.
Part Number Description Control Type Port Size Cycle Time
KZ-KZ1733-1CEBS-D01 EH8, 3/4" Male NPT ON/OFF 3/8" 0.2 Sec
KZ-KZ1754-1CEBS-D01 EH8, 1/2" Male NPT ON/OFF 3/8" 0.2 Sec
KZ-S2B28-1CEBS-D01 EH8, 1/4" Female NPT ON/OFF 1/4" 0.2 Sec
KZ-S2C28-1CEBS-D01 EH8, 3/8" Female NPT ON/OFF 3/8" 0.2 Sec
KZ-S2F33-1CE9S-D01 EH9, 1" Female NPT ON/OFF 1" 0.7 Sec
KZ-S4F22-90EYS-DFV EH9, 1" Female NPT, Bottom Load ON/OFF/ON 1" 3 Sec
KZ-S4H22-90EYS-DFV EH9, 1-1/2" Female NPT, Bottom Load ON/OFF/ON 1-1/2" 3 Sec
Banjo

Banjo

Banjo is a world-class producer of a wide range of mechanical and electrical valves, fittings, and self-priming centrifugal pumps for agriculture and numerous industrial applications that ship to every corner of the globe. Banjo employs an array of molding presses, numerous machining and assembly cells, and an optimized logistics system empowering our production and shipping operations.
