N36-40F40F Dixon Aluminum Double Male - Style N36 - Rocker Lug - 4" Male NST(NH) x 4" Male NST(NH)

N36-40F40F Dixon Aluminum Double Male - Style N36 - Rocker Lug - 4" Male NST(NH) x 4" Male NST(NH)

Save $81.65 Save $81.65
$204.12
$204.12 - $204.12
$204.12
$122.47
$122.47 - $122.47
$122.47

Dixon Fire Fittings
Style N36 Double Male Adapter - Rocker Lug - Aluminum

Seamless aluminum extrusion, hardcoat anodized.
Specifications for Variant SKU: N36-40F40F Dixon
Shape (Orientation): Straight
Ends Configuration: 4in Male NST, 4in Male NST, Some Ends Match
Material(s): Aluminum
Part Number Thread Thread Old Part #: Weight
(Lbs.)
N36-10F10F 1" Male NST(NH) 1" Male NST(NH) - 0.1940
N36-15F15F 1-1/2" Male NST(NH) 1-1/2" Male NST(NH) ADMR15F15F 0.300
N36-15F20T 1-1/2" Male NST(NH) 2" Male NPT - 0.498
N36-15F25F 1-1/2" Male NST(NH) 2-1/2" Male NST(NH) - 0.9460
N36-25F25F 2-1/2" Male NST(NH) 2-1/2" Male NST(NH) ADMR25F25F 0.7700
N36-25F30F 2-1/2" Male NST(NH) 3" Male NST(NH) - 0.9550
N36-25F30T 2-1/2" Male NST(NH) 3" Male NPT - 0.9000
N36-25F40F 2-1/2" Male NST(NH) 4" Male NST(NH) - 2.746
N36-25F40T 2-1/2" Male NST(NH) 4" Male NPT - 2.7460
N36-25F45F 2-1/2" Male NST(NH) 4-1/2" Male NST(NH) - 2.5010
N36-30F30F 3" Male NST(NH) 3" Male NST(NH) - 0.7600
N36-40F40F 4" Male NST(NH) 4" Male NST(NH) - 2.6650
N36-45F45F 4-1/2" Male NST(NH) 4-1/2" Male NST(NH) - 3.0180
N36-60F60F 6" Male NST(NH) 6" Male NST(NH) - 3.9500
N36-15T15F 1-1/2" Male NPT 1-1/2" Male NST(NH) ADMR1515F 0.3200
N36-15T25F 1-1/2" Male NPT 1-1/2" Male NST(NH) - 0.8680
N36-20T20T 2" Male NPT 2" Male NPT - 0.4500
N36-20T25F 2" Male NPT 2-1/2" Male NST(NH) - 0.8450
N36-25T25F 2-1/2" Male NPT Thread 2-1/2" Male NST(NH) ADMR2525F 0.7000
N36-25T30T 2-1/2" Male NPT 3" Male NPT - 0.9420
N36-25T40T 2-1/2" Male NPT 4" Male NPT - 2.5220
N36-30T30F 3" Male NPT 3" Male NST(NH) - 0.8640
N36-40T40F 4" Male NPT 4" Male NST(NH) - 2.7200
N36-40T45F 4" Male NPT 4-1/2" Male NST(NH) - 2.7200
N36-50T60T 5" Male NPT 6" Male NPT - 4.2150
N36-60T60F 6" Male NPT 6" Male NST(NH) ADMR6060F 3.9500
N36-10S10S 1" Male NPSH 1" Male NPSH ADMR10S10S 0.2450
N36-15S15F 1-1/2" Male NPSH 1-1/2" Male NST(NH) - 0.3100
N36-15S15S 1-1/2" Male NPSH 1-1/2" Male NPSH - 0.2900
N36-15S15T 1-1/2" Male NPSH 1-1/2" Male NPT - 0.3130
N36-15S20S 1-1/2" Male NPSH 2" Male NPSH - 0.4540
N36-25S25F 2-1/2" Male NPSH 2-1/2" Male NST(NH) - -
N36-25S25S 2-1/2" Male NPSH 2-1/2" Male NPSH - -
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
