N53-25F40T Dixon Aluminum Swivel Female x Rigid Female Adapter - Style N53 - Rocker Lug - 2-1/2" Female NST(NH) x 4" Female NPT - Old Part #: ASF25F40T

N53-25F40T Dixon Aluminum Swivel Female x Rigid Female Adapter - Style N53 - Rocker Lug - 2-1/2" Female NST(NH) x 4" Female NPT - Old Part #: ASF25F40T

Save $123.73 Save $123.73
$309.32
$309.32 - $309.32
$309.32
$185.59
$185.59 - $185.59
$185.59

Dixon Fire Fittings
Adapters - Rocker Lug - Style N53 - Female Swivel x Female Rigid - Aluminum

Seamless aluminum extrusion, hardcoat anodized.
Specifications for Variant SKU: N53-25F40T Dixon
Shape (Orientation): Straight
Ends Configuration: 2-1/2in Female NST, 4in Female NPT
Material(s): Aluminum
Part Number Swivel Thread Rigid Thread Old Part #: Weight
(Lbs.)
N53-15S15T 1-1/2" Female NPSH 1-1/2" Female NPT - 0.5120
N53-20S20T 2" Female NPSH 2" Female NPT - 0.5620
N53-30S30T 3" Female NPSH 3" Female NPT - 1.8810
N53-60S60T 6" Female NPSH 6" Female NPT - 6.5860
N53-15S15S 1-1/2" Female NPSH 1-1/2" Female NPSH - 0.5380
N53-15F15T 1-1/2" Female NST(NH) 1-1/2" Female NPT - 0.5500
N53-25F20T 2-1/2" Female NST(NH) 2" Female NPT ASF25F20T 1.2130
N53-25F25T 2-1/2" Female NST(NH) 2-1/2" Female NPT ASF250F 2.0000
N53-25F30T 2-1/2" Female NST(NH) 3" Female NPT ASF25F30T 1.8600
N53-25F40T 2-1/2" Female NST(NH) 4" Female NPT ASF25F40T 2.9630
N53-40F40T 4" Female NST(NH) 4" Female NPT ASF40F40T 5.2800
N53-45F40T 4-1/2" Female NST(NH) 4" Female NPT ASF45F40T 4.2000
N53-45F60T 4-1/2" Female NST(NH) 6" Female NPT - 3.6510
N53-50F60T 5" Female NST(NH) 6" Female NPT - 5.0000
N53-60F60T 6" Female NST(NH) 6" Female NPT ASF60F60T 6.0530
N53-15F15F 1-1/2" Female NST(NH) 1-1/2" Female NST(NH) - 0.4650
N53-25F15F 2-1/2" Female NST(NH) 1-1/2" Female NST(NH) - 1.3360
N53-25F25F 2-1/2" Female NST(NH) 2-1/2" Female NST(NH) - 1.2300
N53-25F60F 2-1/2" Female NST(NH) 6" Female NST(NH) - 4.5250
N53-40F40F 4" Female NST(NH) 4" Female NST(NH) - 3.7810
N53-60F45F 6" Female NST(NH) 4-1/2" Female NST(NH) - 5.9090
