PBLSS800 Dixon All Stainless Panel Builder Gauge - 2-1/2" Face, 1/4" Lower Back Mount - 0-800 PSI

PBLSS800 Dixon Valve All Stainless Panel Builder Gauge - 2-1/2" Face, 1/4" Lower Back Mount - 0-800 PSI

$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

All Stainless Panel Builder Gauges - 2-1/2" face, 1/4" lower back mount All of the gauges supplied by Dixon are designed for long, reliable service under rugged conditions. Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement. Fig. Inter. - Figure Interval. Increments between PSI numbers on gauge face. Grad. Inter. - Graduation Interval. Fractional increments between PSI numbers on gauge face.
Specifications for Variant SKU: PBLSS800 Dixon
Features:
  • Suitable for corrosive environments.
  • Used in gaseous and liquid media.
  • ASME B40.100 Grade A 2/1/2% full scale accuracy.
  • 316L stainless steel wetted parts materials.
  • Media temperature 212°F maximum.
  • Dial - white aluminum with black lettering; stop pin.
  • Pointer - black aluminum.
  • Glycerin filled case.
  • Laminated safety glass window lens.
  • Fits industry standard 2.56" panel hole cutout.
Part Number Fig. Inter. Grad Inter. Min/Max Temp PSI Weight (Lbs.)
PBLSS15 3 .2 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-15 0.4785
PBLSS30 5 .5 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-30 0.4865
PBLSS60 10 1 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-60 0.4800
PBLSS100 20 2 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-100 0.6500
PBLSS160 20 2 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-160 0.4930
PBLSS200 50 5 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-200 0.4900
PBLSS300 50 5 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-300 0.4850
PBLSS400 100 10 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-400 0.4900
PBLSS600 100 10 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-600 0.6600
PBLSS800 200 20 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-800 0.5000
PBLSS1000 200 20 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-1000 0.6500
PBLSS1500 300 20 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-1500 0.4785
PBLSS2000 500 50 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-2000 0.4850
PBLSS3000 500 50 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-3000 0.6800
PBLSS5000 1000 100 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-5000 0.6500

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
