PSBJ731-2G by Parker | Pneumatic Threshold Sensor | 1/8" Male BSPP Thread | 14 mm Hex | Straight | Bolt Material: Brass | Polymer

Save $4.33

$59.50

$59.50 - $59.50

$59.50

$55.17

$55.17 - $55.17

$55.17

by Parker Hannifin
Threshold Sensor Fittings:PSBJ731 Pneumatic Threshold Sensor - 4mm Pilot

Quantity

Specifications for Variant SKU: PSBJ731-2G Parker
Series:	PSBJ731 Series
Shape (Orientation):	Straight
Material(s):	Polymer, Brass
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Valved

Product Features:	Polymer body Brass screw NBR seal
Markets:	Factory/Process Automation Packaging Petrochemical Pneumatics Semi-Conductor
Applications:	Robotics Packaging Textile Machine Tools Pneumatic Systems
Pressure Range:	45 to 115 PSI (3.1 to 7.9 bar)
Temperature Range:	+5° to +140° F (-15° to +60° C)
Breaking Pressure:	8.5 PSI (0.5 bar)
Response Time:	3 MS
Model PSPE Pressure Range:	45 to 115 PSI (3.1 to 7.9 bar)
Breaking Pressure:	8.5 PSI (0.5 bar)
Current Rating:	5A/250VAC – 5W/48VDC
Compatible Tubing:	Semi-rigid nylon Polyurethane 95 Durometer Shore A Nylon Fluoropolymer


Part Number	BSPP	Hex	H	L
PSBJ731-M5	M5X0.8	8 mm	16 mm	43.5 mm
PSBJ731-2G	1/8"	14 mm	23 mm	44.5 mm
PSBJ731-4G	1/4"	17 mm	28 mm	46.5 mm
PSBJ731-6G	3/8"	22 mm	29 mm	49.0 mm
