S6438X550X120CS Dixon King Crimp® | Large Sleeve | 6.44" Sleeve ID | 6" Hose ID | 0.120" Sleeve Wall Thickness | 5.50" Length | Carbon Steel

Save $21.51

$53.78

$53.78 - $53.78

$53.78

$32.27

$32.27 - $32.27

$32.27

Dixon Valve & Coupling
King Crimp® Style | Large Sleeve

Recommended for low-pressure discharge and suction service for compatible liquids.

Specifications for Variant SKU: S6438X550X120CS Dixon
Brand:	King Crimp®
Material(s):	Carbon Steel

Safety Notes:
For use with King Crimp Style Short Combination Nipples. Only use the crimp style shanks with the crimp style sleeves and ferrules. Due to differences in dimensions and tolerances for safety reasons, do not interchange other manufacturer's products with Dixon products.

Carbon Steel Part Number	Hose I.D.	Sleeve I.D.	Sleeve Wall Thickness	Sleeve Overall Length
S6438X550X120CS	6"	6.44"	0.120"	5.50"
S700X400X120CS	6"	7.00"	0.120"	4.00"

S838X600X120CS	8"	8.38"	0.120"	6.00"
S850X650X120CS	8"	8.50"	0.120"	6.50"
S875X600X120CS	8"	8.75"	0.120"	6.00"
S898X875X120CS	8"	8.98"	0.120"	8.75"
S900X400X090CS	8"	9.00"	0.090"	4.00"
S900X400X120CS	8"	9.00"	0.120"	4.00"
S900X600X120CS	8"	9.00"	0.120"	6.00"
S912X600X120CS	8"	9.12"	0.120"	6.00"
S915X600X120CS	8"	9.15"	0.120"	6.00"
S925X400X120CS	8"	9.25"	0.120"	4.00"
S925X600X120CS	8"	9.25"	0.120"	6.00"
S950X400X120CS	8"	9.50"	0.120"	4.00"
S950X600X120CS	8"	9.50"	0.120"	6.00"
S975X600X120CS	8"	9.75"	0.120"	6.00"

S1050X750X120CS	10"	10.50"	0.120"	7.50"
S1100X600X120CS	10"	11.00"	0.120"	6.00"
S1125X750X120CS	10"	11.25"	0.120"	7.50"
S1175X600X120CS	10"	11.75"	0.120"	6.00"
S1175X750X120CS	10"	11.75"	0.120"	7.50"

S1244X900X120CS	12"	12.44"	0.120"	9.00"
S1275X800X120CS	12"	12.75"	0.120"	8.00"
S1325X750X120CS	12"	13.25"	0.120"	7.50"
S1325X800X120CS	12"	13.25"	0.120"	8.00"
S1325X950X120CS	12"	13.25"	0.120"	9.50"

S1400X800X120CS	14"	14.00"	0.120"	8.00"
S1400X950X120CS	14"	14.00"	0.120"	9.50"
