TR4XF-32 Alfagomma by Kuriyama | TR4XF Series | SAE 100R4 | 4-Wire | Extra-Flexible Oil Return Hydraulic Hose | 2" ID | 2.44" OD | 100 PSI

TR4XF-32 Alfagomma by Kuriyama | TR4XF Series | SAE 100R4 | 4-Wire | Extra-Flexible Oil Return Hydraulic Hose | 2" ID | 2.44" OD | 100 PSI

Save $5.29 Save $5.29
$18.51
$18.51 - $18.51
$18.51
$13.22
$13.22 - $13.22
$13.22

Kuriyama of America Inc.
Alfagomma | TR4XF Series | SAE 100R4 | 4-Wire | Extra-Flexible Oil Return Hydraulic Hose

Ideal for low pressure return lines or suction lines with half the bend radius requirements of SAE J517 100R4, service with petroleum based hydraulic fluids, water-glycol and water-fire resistant hydraulic fluids, oil, lubricants, crude oil, fuel oils and water.

This item is sold as Bulk Length and thus may come in multiple sections.
Specifications for Variant SKU: TR4XF-32 Kuriyama
Brand: Alfagomma
Series: TR4XF Series
Hose Color(s): Black
Dash Size: -32
Internal Diameter: 2in
Outer Diameter: 2.44in
Tubing Construction: NBR
Cover Construction: Chloroprene
Applicable Specs & Approvals: SAE 100R4, SAE J517
Application: Low pressure return lines or suction lines with half the bend radius requirements of SAE J517 100R4, service with petroleum based hydraulic fluids, water-glycol and water-fire resistant hydraulic fluids, oil, lubricants, crude oil, fuel oils and water. SAE Rating: Meets or exceeds SAE 100R4
Other Ratings: SAE J517 100R4, Tube: Black, conductive NBR.
Reinforcement: Textile reinforced with four spiral wire helix to prevent collapsing. Cover: Black CR... oil, fuel, weather, ozone and abrasion-resistant.
Temperature Range: -40°F (-40°C) to +212°F (+100°C) constant operation.
Maximum Operating Temperature: +257°F (+125°C)		 Air Maximum Temperature: +175°F (+80°C)
Note: Operating temperatures in excess of +212°F (+100°C) may materially reduce the life of the hose.
Branding: ALFAGOMMA - Italy - T634 (psi) - SAE 100R4 - (SIZE) - Date
Part Number ID OD Max. Working
Pressure*		 Min Bend
Radius		 Weight
(in.) (mm) (in.) (mm) PSI (in.) (mm) (lbs./ft.)
TR4XF-12 3/4" 19.1mm 1.18" 30.0mm 300 PSI 1.5" 38.1mm 0.41 lbs/ft
TR4XF-16 1" 25.4mm 1.42" 36.0mm 250 PSI 2.0" 50.8mm 0.51 lbs/ft
TR4XF-20 1-1/4" 31.8mm 1.69" 43.0mm 200 PSI 2.5" 63.5mm 0.62 lbs/ft
TR4XF-24 1-1/2" 38.1mm 1.93" 49.0mm 150 PSI 3.0" 76.2mm 0.72 lbs/ft
TR4XF-32 2" 50.8mm 2.44" 62.0mm 100 PSI 4.0" 101.6mm 0.93 lbs/ft
TR4XF-40 2-1/2" 63.0mm 2.99" 76.0mm 60 PSI 4.9" 125.0mm 1.47 lbs/ft
TR4XF-48 3" 76.0mm 3.50" 89.0mm 60 PSI 5.9" 152.0mm 1.75 lbs/ft

* Minimum burst pressure 4-to-1 safety factor.
