TR5HT-10 Alfagomma by Kuriyama | TR5HT Evolution Series | SAE 100R5 | Hydraulic Hose | 1-Wire Braid | 1/2" ID | 0.92" OD | 1750 PSI

TR5HT-10 Alfagomma by Kuriyama | TR5HT Evolution Series | SAE 100R5 | Hydraulic Hose | 1-Wire Braid | 1/2" ID | 0.92" OD | 1750 PSI

Save $3.38 Save $3.38
$11.83
$11.83 - $11.83
$11.83
$8.45
$8.45 - $8.45
$8.45

Kuriyama of America Inc.
Alfagomma | TR5HT Evolution Series | SAE 100R5 | Hydraulic Hose | 1-Wire Braid

Medium pressure service hydraulic petroleum based oil line in impulse applications; lube oil, diesel fuel lines and oil for Bio-diesel; applications such as air brakes, power steering, turbocharger oil supplies, tilt cab cylinders, transmission coolant, engine coolant and filtration lines.

Specially designed for high temperature applications. Meets or exceeds requirements of SAE 100 R5 for traditional hydraulic applications.

This item is sold as Bulk Length and thus may come in multiple sections.
Specifications for Variant SKU: TR5HT-10 Kuriyama
Brand: Alfagomma, Evolution
Series: TR5HT Series
Hose Color(s): Blue
Dash Size: -10
Internal Diameter: 0.5in
Outer Diameter: 0.92in
Tubing Construction: Synthetic Rubber
Cover Construction: Polyester
Applicable Specs & Approvals: SAE 100R5
Special Properties: High Temperature
Application: Medium pressure service hydraulic petroleum based oil line in impulse applications; lube oil, diesel fuel lines and oil for Bio-diesel;
applications such as air brakes, power steering, turbocharger oil supplies, tilt cab cylinders, transmission coolant, engine coolant and filtration lines.		 SAE Rating: Meets or exceeds SAE 100R5
Other Ratings: - Tube: Oil-resistant synthetic rubber.
Reinforcement: One high tensile steel braid. Cover: Polyester textile braid.
Temperature Range: -40°F (-40°C) to +300°F (+150°C) constant operation. Air Maximum Temperature: Up to 5/8" = +185°F (+85°C)
Over 3/4" = +230°F (+110°C)
Branding: Alfagomma R5 Evolution HT ...WP ...MPa (...PSI) - SAE 100 R5... Q/YR
Part Number ID OD Max. Working
Pressure*		 Min Bend
Radius		 Weight
(in.) (mm) (in.) (mm) PSI (in.) (mm) (lbs./ft.)
TR5HT-04 3/16" 4.8mm 0.52" 13.2mm 3000 3.0" 76.2mm 0.16 lbs/ft
TR5HT-05 1/4" 6.4mm 0.58" 14.8mm 3000 3.4" 86.4mm 0.19 lbs/ft
TR5HT-06 5/16" 7.9mm 0.68" 17.3mm 2250 4.0" 101.6mm 0.24 lbs/ft
TR5HT-08 13/32" 10.3mm 0.77" 19.5mm 2000 4.6" 116.8mm 0.28 lbs/ft
TR5HT-10 1/2" 12.7mm 0.92" 23.4mm 1750 5.5" 139.7mm 0.38 lbs/ft
TR5HT-12 5/8" 15.9mm 1.08" 27.4mm 1500 6.5" 165.1mm 0.46 lbs/ft
TR5HT-16 7/8" 22.2mm 1.24" 31.4mm 800 7.3" 185.4mm 0.47 lbs/ft
TR5HT-20 1-1/8" 28.6mm 1.50" 38.1mm 625 9.0" 228.6mm 0.58 lbs/ft
TR5HT-24 1-3/8" 34.9mm 1.75" 44.5mm 500 10.5" 266.7mm 0.72 lbs/ft
TR5HT-32 1-13/16" 46.0mm 2.22" 56.4mm 350 13.2" 335.3mm 0.91 lbs/ft

* Minimum burst pressure 4-to-1 safety factor.
