TVSEC-G300 Dixon Valve Sanitary Air & Vacuum Relief Tank Vent Valve - 3" Tube OD - 304 Stainless Steel

TVSEC-G300 Dixon Valve Sanitary Air & Vacuum Relief Tank Vent Valve - 3" Tube OD - 304 Stainless Steel

Save $125.60 Save $125.60
$412.79
$412.79 - $412.79
$412.79
$287.19
$287.19 - $287.19
$287.19

Dixon Sanitary Fittings Sanitary Valve - Air & Vacuum Relief Tank Vent Valve

Used to relieve pressure or vacuum when product filling or evacuation in a tank
Specifications for Variant SKU: TVSEC-G300 Dixon
Shape (Orientation): Straight
Material(s): 304 Stainless Steel
Seal Material(s): EPDM
Features:
  • Triple action valve relieves pressure as the fluid level rises while filling a tank, relieves vacuum as the fluid level drops while emptying a tank and seals under equal pressure.
  • Stainless steel screen surrounds the entire vacuum and pressure flow area.
  • Clamp connection standard.
  • 1/4" FNPT connection for gas inlet, plug also supplied.
Construction:
  • 304 stainless steel, EPDM elastomer
Specifications:
  • Vacuum break: 2" water column, 0.1 PSI
  • Pressure relief: 22" water column, 0.8 PSI
  • Maximum temperature and pressure rating: 3 PSI @ 70°F (21°C)
  • Maximum flow rate: 500 GPM
Part Number Tube OD A
TVSEC-G200 2" 2.52"
TVSEC-G300 3" 3.58"
TVSEC-G400 4" 4.68"
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
