VP500P-6 by Parker | Ball Valves | 3/8" Female PTF Pipe Thread | 15/16" Hex (B) | 15/16" Hex (C) | 4.90" Length | Straight | Brass

Save $17.44

$43.60

$43.60 - $43.60

$43.60

$26.16

$26.16 - $26.16

$26.16

by Parker Hannifin
Ball Valves Brass Series 500:Locking Handle, Female Pipe Ends VP500P

Specifications for Variant SKU: VP500P-6 Parker
Series:	VP500P Series
Shape (Orientation):	Straight
Material(s):	Brass, Chrome-Plated Brass, Steel
Seal Material(s):	PTFE
Special Properties:	Valved

Specification:
Product Features:	Forged brass body Chrome plated brass ball PTFE seats/seals Steel handle
Style:	V-Valve VP-Valve, padlocking handle VV-Valve, vented VVP-Valve, vented, padlocking handle
Type:	500-Female/Female PTF ports
Material:	P-Brass PN-Nickel plated
Options:	01-Stainless Steel Ball & Stem 02-Stainless Steel Handle & Nut 03-Stainless Steel Ball, Stem, Handle & Nut 04-Tee Handle 08-Unmarked yellow vinyl handle cover 21-Oval Handle
Temperature Range:	0° to +350° F (-17.7° to +176.6° C)
Pressure Range:	600 WOG , Cold Non-shock Saturated Steam up to 150 PSI (10.3 bar) Vacuum Service to 29 Inches Hg Vented up to 250 PSI (17.2 bar)

For Use With 5/16" Ø Shank Lock; .33Ø


Part Number	Pipe Thread (PTF)	Hex (B)	Hex (C)	H	L	M	N	Flow Diameter (D)
VP500P-4	1/4"	15/16"	15/16"	3.96"	4.90"	2.03"	2.47"	.375"
VP500P-6	3/8"	15/16"	15/16"	3.96"	4.90"	2.03"	2.47"	.375"
VP500P-8	1/2"*	1-1/16"	1-1/16"	3.96"	5.00"	2.20"	2.58"	.500"
VP500P-12	3/4"**	1-1/4"	1-5/16"	3.96"	5.25"	2.42"	2.81"	.685"
VP500P-16	1"**	1-1/2"	1-9/16"	3.96"	5.34"	2.75"	3.08"	.875"

For Use With 9/16" Ø Shank Lock; .33Ø


Part Number	Pipe Thread	Hex (B)	Hex (C)	H	L	M	N	Flow Diameter (D)
VP500P-20	1-1/4"**	1-15/16"	1-15/16"	6.22"	8.05"	3.66"	4.04"	1.180"
VP500P-24	1-1/2"**	2-1/8"	2-1/8""	6.22"	8.23"	4.02"	4.52"	1.500"
VP500P-32	2"**	2-11/16"	2-11/16"	6.22"	8.60"	4.76"	5.07"	1.890"

*PTF Special Short. **PTF SPL Extra Short
