VVP502P-16 by Parker | Ball Valve | 1" Female PTF Pipe Thread | 1-1/2" Hex (B) | 1-9/16" (C) | 5.34" Length | Straight | Brass | Pack of 8

Save $52.64

$579.07

$579.07 - $579.07

$579.07

$526.43

$526.43 - $526.43

$526.43

by Parker Hannifin
Ball Valves Brass Series 502:OSHA 29 CFR Part 1910 Vented, Locking Handle, Female Pipe Ends, Panel Mount VVP502P

Unit Price: $65.80 per EA

Package Quantity: 8 EA

Quantity

More payment options

Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: VVP502P-16 Parker \| 8 \|
Series:	VVP502P Series
Shape (Orientation):	Straight
Material(s):	Brass, Chrome-Plated Brass, Steel
Seal Material(s):	PTFE

Specification:
Product Features:	Forged brass body Chrome plated brass ball PTFE seats/seals Steel handle
Style:	V-Valve VP-Valve, padlocking handle VV-Valve, vented VVP-Valve, vented, padlocking handle
Type:	502-Female/Female PTF ports
Material:	P-Brass PN-Nickel plated
Options:	01-Stainless Steel Ball & Stem 02-Stainless Steel Handle & Nut 03-Stainless Steel Ball, Stem, Handle & Nut 04-Tee Handle 08-Unmarked yellow vinyl handle cover 21-Oval Handle
Temperature Range:	0° to +350° F (-17.7° to +176.6° C)
Pressure Range:	600 WOG , Cold Non-shock Saturated Steam up to 150 PSI (10.3 bar) Vacuum Service to 29 Inches Hg Vented up to 250 PSI (17.2 bar)


Part Number	Female Pipe Thread (PTF)	Hex (B)	Hex (C)	F	G	K	H	L	M	N	Flow Diameter (D)
VVP502P-4	1/4"	15/16"	15/16"	.50"	1.12"	1.11"	3.96"	4.90"	2.03"	2.47"	.375"
VVP502P-6	3/8"	15/16"	15/16"	.50"	1.12"	1.11"	3.96"	4.90"	2.03"	2.47"	.375"
VVP502P-8	1/2"*	1-1/16"	1-1/16"	.50"	1.12"	1.23"	3.96"	5.06"	2.20"	2.58"	.500"
VVP502P-12	3/4"**	1-1/4"	1-5/16"	.87"	1.37"	1.45"	3.96"	5.25"	2.42"	2.81"	.685"
VVP502P-16	1"**	1-1/2"	1-9/16"	.87"	1.37"	1.58"	3.96"	5.34"	2.75"	3.08"	.875"

*PTF Special Short. **PTF SPL Extra Short

For use with 5/16" Ø shank lock
