W68PLP-10M-6R by Parker | Prestolok PLP Push-to-Connect Fittings | Threaded Fitting | 10mm Connector x 3/8" Male BSPT Thread | 11/16" Hex | 27.18mm Length | 7.925mm Flow Dia. | Straight | Nickel-Plated Brass

Save $5.78

$13.57

$13.57 - $13.57

$13.57

$7.79

$7.79 - $7.79

$7.79

by Parker Hannifin
Push-to-Connect Fittings:W68PLP Male Connector – BSPT

Specifications for Variant SKU: W68PLP-10M-6R Parker
Series:	W68PLP Series
Shape (Orientation):	Straight
Material(s):	Nickel-Plated Brass, Stainless Steel, PVDF
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Corrosion Resistance, Flame Resistant Release Button

Product Features:	Stainless steel grab ring Nickel-plated brass body Nitrile seal Flame resistant release button Corrosion resistance Inch and metric tube connections NPT, BSPP, BSPT, and metric threads Meets UL94 V-0 Flame Resistance Standard
Markets:	Industrial Automotive Climate Control Welding Robotic Welding
Compatible Media:	Compressed Air Inert Gases Vacuum
Pressure Range:	Up to 300 PSI (20.6 bar) depending on tubing
Temperature Range:	0° to +200° F (-17.7° to 93.3° C)
Vacuum Rating:	28" Hg
Compatible Tubing:	95FR Microweld Polyethylene Polypropylene Semi Rigid Nylon Rigid Nylon Polyurethane 95 Durometer Shore A


Part Number	Tube Size	Thread BSPT	Hex (C)	Length (L)	Flow Diameter (D)
W68PLP-4M-2R	4 mm	1/8"	7/16"	20.41 mm	3.175 mm
W68PLP-4M-4R	4 mm	1/4"	9/16"	27.1 8mm	3.175 mm
W68PLP-6M-2R	6 mm	1/8"	1/2"	22.00 mm	4.775 mm
W68PLP-6M-4R	6 mm	1/4"	9/16"	26.74 mm	4.775 mm
W68PLP-6M-6R	6 mm	3/8"	11/16"	26.46 mm	4.775 mm
W68PLP-8M-2R	8 mm	1/8"	9/16"	29.80 mm	6.350 mm
W68PLP-8M-4R	8 mm	1/4"	9/16"	26.24 mm	6.350 mm
W68PLP-8M-6R	8 mm	3/8"	11/16"	27.51 mm	6.350 mm
W68PLP-10M-4R	10 mm	1/4"	5/8"	29.72 mm	7.925 mm
W68PLP-10M-6R	10 mm	3/8"	11/16"	27.18 mm	7.925 mm
W68PLP-10M-8R	10 mm	1/2"	7/8"	34.24 mm	7.925 mm
W68PLP-12M-4R	12 mm	1/4"	13/16"	36.90 mm	8.738 mm
W68PLP-12M-6R	12 mm	3/8"	13/16"	30.85 mm	9.525 mm
W68PLP-12M-8R	12 mm	1/2"	7/8"	33.85 mm	9.525 mm
