W68PLPR-4-1 by Parker | Prestolok PLP Push-to-Connect Fittings | Threaded Fitting | 1/4" Round Body Connector x 1/16" Male NPTF Thread | 5/32" Hex | Straight | Nickel-Plated Brass | Pack of 10

Save $99.25

$248.12

$248.12 - $248.12

$248.12

$148.87

$148.87 - $148.87

$148.87

by Parker Hannifin
Push-to-Connect Fittings:68PLPR Round Male Connector – NPTF/UNF

Package Quantity: 10 Units

Specifications for Variant SKU: W68PLPR-4-1 Parker \| 10 \|
Series:	68PLPR Series
Shape (Orientation):	Straight
Material(s):	Nickel-Plated Brass, Stainless Steel, PVDF
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Corrosion Resistance, Flame Resistant Release Button

Product Features:	Stainless steel grab ring Nickel-plated brass body Nitrile seal Flame resistant release button Corrosion resistance Inch and metric tube connections NPT, BSPP, BSPT, and metric threads Meets UL94 V-0 Flame Resistance Standard
Markets:	Industrial Automotive Climate Control Welding Robotic Welding
Compatible Media:	Compressed Air Inert Gases Vacuum
Pressure Range:	Up to 300 PSI (20.6 bar) depending on tubing
Temperature Range:	0° to +200° F (-17.7° to 93.3° C)
Vacuum Rating:	28" Hg
Compatible Tubing:	95FR Microweld Polyethylene Polypropylene Semi Rigid Nylon Rigid Nylon Polyurethane 95 Durometer Shore A


Part Number	Tube Size	Thread Size NPTF	Internal Hex Broach	Body Diameter O.D.	Length (L)	Flow Diameter
68PLPR-2-0*	1/8"	10-32	3/32"	3/8"	.89"	.094"
68PLPR-5/32-0*	5/32"	10-32	3/32"	3/8"	.97"	.094"
68PLPR-4-0*	1/4"	10-32	3/32"	1/2"	.95"	.094"
W68PLPR-5/32-1	5/32"	1/16"	1/8"	3/8"	.87"	.125"
W68PLPR-5/32-2	5/32"	1/8"	1/8"	7/16"	.79"	.125"
W68PLPR-4-1	1/4"	1/16"	5/32"	1/2"	1.06"	.156"
W68PLPR-4-2	1/4"	1/8"	3/16"	1/2"	.88"	.188"
W68PLPR-4-4	1/4"	1/4"	3/16"	5/8"	.99"	.188"

*10-32 seal is neoprene
