Aeroquip® by Danfoss
BSPP 60° Seat Plug

(Formerly Eaton Aeroquip)

Specifications for Variant SKU: FF91571-04S Danfoss
Brand:	Aeroquip
Ends Configuration:	1/4in Male BSPP
Material(s):	Carbon Steel

Specifications:
Ref. Performance per ISO 8434-6


Steel Part Number	Tube OD	Thread T1	A	Hex E
FF91571-04S	0.25"	G 1/4-19	0.71"	0.75"
FF91571-06S	0.38"	G 3/8-19	0.85"	0.87"
FF91571-08S	0.50"	G 1/2-14	1.02"	1.06"
FF91571-12S	0.75"	G 3/4-14	1.16"	1.26"
FF91571-16S	1.00"	G 1-11	1.34"	1.61"
FF91571-20S	1.25"	G 1-1/4-11	1.48"	1.97"
FF91571-24S	1.50"	G 1-1/2-11	1.57"	2.17"
FF91571-32S	2.00"	G 2-11	1.71"	2.76"
