01VA07CC030602 AIGNEP | 01V Control Valves Series | 5/3 Double Solenoid Ext Pilot | Closed Center | Spring Centered | G-Thread 1/4" | 220V AC/5VA coil | LED Con
01VA07CC030602 by AIGNEP | 01V Control Valves Series | 5/3 Double Solenoid Ext Pilot | Closed Center | Spring Centered | G-Thread 1/4" | 220V AC/5VA coil | LED Con
01VA07CC030602 AIGNEP | 01V Control Valves Series | 5/3 Double Solenoid Ext Pilot | Closed Center | Spring Centered | G-Thread 1/4" | 220V AC/5VA coil | LED Con

01VA07CC030602 by AIGNEP | 01V Control Valves Series | 5/3 Double Solenoid Ext Pilot | Closed Center | Spring Centered | G-Thread 1/4" | 220V AC/5VA coil | LED Con

Save $62.55 Save $62.55
$156.37
$156.37 - $156.37
$156.37
$93.82
$93.82 - $93.82
$93.82
Specifications for Variant SKU: 01VA07CC030602 AIGNEP
Series: 01V Control Valves Series
Ends Configuration: 1/4in Female BSPP, 1/4in Female BSPP, Some Ends Match
Material(s): Plastic
SOLENOID ASSISTED
Technical Characteristics:
Operating Rating: 0 ÷ 10 bar
0 ÷ 145 psi		 Operating Pressure: Monostable: 2 ÷ 10 bar / 29 ÷ 145 psi
Bistable: 1 ÷ 10 bar / 14.5 ÷ 145 psi
Temperature: Min: 14°F (-10°C)
Max: 140°F (60°C)		 Component Parts and Materials: • Anodised and painted aluminium body
• Chemical nickel-plated spool
• NBR seals
Part Number Solenoid Voltage Minimum Power Ways Reactuation Function Size
01VA07CC020102 12V DC 3W 5/3 Monostable Spring Return Closed Center (CC) G 1/8"
01VA07CC020202 24V DC 3W 5/3 Monostable Spring Return Closed Center (CC) G 1/8"
01VA07CC020302 24V DC 2W 5/3 Monostable Spring Return Closed Center (CC) G 1/8"
01VA07CC020402 24V AC 5VA 5/3 Monostable Spring Return Closed Center (CC) G 1/8"
01VA07CC020502 110V AC 5VA 5/3 Monostable Spring Return Closed Center (CC) G 1/8"
01VA07CC020602 220V AC 5VA 5/3 Monostable Spring Return Closed Center (CC) G 1/8"
01VA07CC030102 12V DC 3W 5/3 Monostable Spring Return Closed Center (CC) G 1/4"
01VA07CC030202 24V DC 3W 5/3 Monostable Spring Return Closed Center (CC) G 1/4"
01VA07CC030302 24V DC 2W 5/3 Monostable Spring Return Closed Center (CC) G 1/4"
01VA07CC030402 24V AC 5VA 5/3 Monostable Spring Return Closed Center (CC) G 1/4"
01VA07CC030502 110V AC 5VA 5/3 Monostable Spring Return Closed Center (CC) G 1/4"
01VA07CC030602 220V AC 5VA 5/3 Monostable Spring Return Closed Center (CC) G 1/4"
AIGNEP

AIGNEP

For over 40 years, AIGNEP has been a leading manufacturer of compressed air and industrial fluid fittings. Our products are widely known for their high quality and Italian design: pneumatic cylinders and solenoid valves, fluid process control valves “FLUIDITY”, compressed air pipeline “INFINITY”, fittings and quick couplings for every fluid media.
