0677 00 10 by Parker | Legris Miniature Silencer | G1/8" Male BSPP Thread | Nickel-Plated Brass | Pack of 10

Save $0.62

$33.15

$33.15 - $33.15

$33.15

$32.53

$32.53 - $32.53

$32.53

by Parker Hannifin
Silencers:0677 Miniature Silencer, Male BSPP Thread

Package Quantity: 10 Units

Quantity

Specifications for Variant SKU: 0677 00 10 Parker \| 10 \|
Series:	0677 Series
Shape (Orientation):	No Orientation
Material(s):	Nickel-Plated Brass
Special Properties:	Silicone Free

Technical Characteristics:	Compatible Fluids: Compressed air Working Pressure: Polyethylene: 0 to 10 bar Sintered bronze: 0 to 12 bar 316L Stainless Steel: 0 to 12 bar Working Temperature: Polyethylene: -10°C to +80°C Sintered bronze: -20°C to +150°C 316L Stainless Steel: -20°C to +180°C
Advantages:	3 materials available - Polyethylene: optimum exhaust flow rate and noise attention - Sintered bronze: robust and economic - 316L stainless Steel: increased chemical and mechanical resistance incorporated flow control regulator on 2 versions
Regulations:	RoHS PED REACH 2003/10/CE OSHA
Component Materials:	Body: Brass (0670-0673-0675-0671-0677-0672) Polymer (0674-0676) Stainless Steel (0682-0683) Silencer: Sintered Bronze (0670-0673-0675-0671-0677-0672) Polymer (0674-0676) Stainless Steel (0682-0683)


Part Number	C	G	H	Wt (Oz)
0677 00 10	G1/8"	5.5 mm	4 mm	.002 oz
0677 00 13	G1/4"	6 mm	4.5 mm	.003 oz
0677 00 17	G3/8"	9.5 mm	4 mm	.006 oz
0677 00 21	G1/2"	12.5 mm	5.5 mm	.012 oz
0677 00 34	G1"	24 mm	7 mm	.025 oz
