1-1/2" 4SH (EN856) Couplamatic Four Spiral Extra High Pressure Import Hydraulic Hose - 1-1/2" ID - Bulk

1-1/2" 4SH - EN856 by Couplamatic | Four Spiral Extra High Pressure | Import Hydraulic Hose | 1-1/2" ID | 50ft Bulk Length

Save $535.33

$1,338.33

$1,338.33 - $1,338.33

$1,338.33

$803.00

$803.00 - $803.00

$803.00

Couplamatic Systems Inc.
4 High Tensile Steel Spirals - 4SH Four Spiral Extra High Pressure Import Hydraulic Hose - 4SH (EN856)

Specifications for Variant SKU: 1-1/2" 4SH Couplamatic \| 50 \|
Series:	4SH Series
Hose Color(s):	Black
Dash Size:	-24
Internal Diameter:	1.50in
Outer Diameter:	2.085in
Applicable Specs & Approvals:	Applicable MSHA Standards
Compatible with the following Series:	6GC Series \| 4SH Series

DIN 4SH — Four Spiral

4SH Four Spiral Extra High Pressure Hydraulic Hose

DIN 4SH four-spiral hose for the very highest pressure hydraulic circuits, with a white layline and an MSHA approved abrasion and flame resistant cover.

1

What is this hose used for?

Very High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

Cover

Abrasion and Flame Resistant Black Cover, MSHA Approved, White Layline

Reinforcement

4 High Tensile Steel Spirals

Temperature

-40°F to +212°F (-40°C to +100°C)

Size Range

5/8" to 1-1/2"

3

What are the main product features?

Four high tensile steel spirals — extra high pressure hydraulic capability.
DIN 4SH construction — exceeds standard SAE spiral hose ratings.
White layline — clear identification on the equipment.
MSHA approved cover — abrasion and flame resistant black cover.
No skive required — terminates with 4SH Series and 6GC Series no-skive couplings.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
5/8" 4SH	5/8"	1.130"	6,090 lbs.	24,360 lbs.	9.5"	97 lbs.	Bulk
3/4" 4SH	3/4"	1.268"	6,090 lbs.	24,360 lbs.	11"	112 lbs.	Bulk
1" 4SH	1"	1.523"	5,510 lbs.	22,040 lbs.	13.5"	131 lbs.	Bulk
1-1/4" 4SH	1-1/4"	1.791"	5,075 lbs.	20,300 lbs.	18"	181 lbs.	Bulk
1-1/2" 4SH	1-1/2"	2.085"	4,205 lbs.	16,820 lbs.	22"	241 lbs.	Bulk

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.
