1/4" 57MB-2 Couplamatic Domestic Thin Cover 2-Wire Hydraulic Hose (SAE 100R2AT) - 1/4" ID - 250ft

1/4" 57MB-2 by Couplamatic | Domestic Thin Cover | 2-Wire Hydraulic Hose | SAE 100R2AT | 1/4" ID | 250ft

Save $7.85

$818.52

$818.52 - $818.52

$818.52

$810.67

$810.67 - $810.67

$810.67

Couplamatic Systems Inc.
Two Wire Braid Hoses - 57MB-2 Domestic Thin Cover 2-Wire Hydraulic Hose - SAE 100R2AT

Package Quantity: 250 FT

Quantity

Specifications for Variant SKU: 1/4" 57MB-2 Couplamatic \| 250 \|
Series:	57MB-2 Series
Hose Color(s):	Black
Dash Size:	-4
Internal Diameter:	0.25in
Outer Diameter:	0.593in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R2AT
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series \| GW Series \| Reusable Couplings Series

Applications:	High Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R2AT
Cover:	Abrasion and Flame Resistant Cover, MSHA Approved	Reinforcement:	Two Wire Braids
Temperature:	-40F to +212F (-40C to +100C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" 57MB-2	1/4"	0.593"	5,000 lbs.	20,000 lbs.	4"	24 lbs.	250ft
3/8" 57MB-2	3/8"	0.750"	4,000 lbs.	16,000 lbs.	5"	34 lbs.	250ft
1/2" 57MB-2	1/2"	0.875"	3,500 lbs.	14,000 lbs.	7"	43 lbs.	250ft
5/8" 57MB-2	5/8"	1.010"	2,750 lbs.	11,000 lbs.	8"	51 lbs.	250ft
3/4" 57MB-2	3/4"	1.158"	2,250 lbs.	9,000 lbs.	9.5"	61 lbs.	250ft
1" 57MB-2	1"	1.500"	2,000 lbs.	8,000 lbs.	12"	88 lbs.	250ft

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
