3/8" 57MB-2 Couplamatic Domestic Thin Cover 2-Wire Hydraulic Hose (SAE 100R2AT) - 3/8" ID - 250ft

3/8" 57MB-2 by Couplamatic | Domestic Thin Cover | 2-Wire Hydraulic Hose | SAE 100R2AT | 3/8" ID | 250ft

Save $8.14

$948.14

$948.14 - $948.14

$948.14

$940.00

$940.00 - $940.00

$940.00

Couplamatic Systems Inc.
Two Wire Braid Hoses - 57MB-2 Domestic Thin Cover 2-Wire Hydraulic Hose - SAE 100R2AT

Package Quantity: 250 FT

Quantity

Specifications for Variant SKU: 3/8" 57MB-2 Couplamatic \| 250 \|
Series:	57MB-2 Series
Hose Color(s):	Black
Dash Size:	-6
Internal Diameter:	0.375in
Outer Diameter:	0.75in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R2AT
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series \| GW Series \| Reusable Couplings Series

Applications:	High Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R2AT
Cover:	Abrasion and Flame Resistant Cover, MSHA Approved	Reinforcement:	Two Wire Braids
Temperature:	-40F to +212F (-40C to +100C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" 57MB-2	1/4"	0.593"	5,000 lbs.	20,000 lbs.	4"	24 lbs.	250ft
3/8" 57MB-2	3/8"	0.750"	4,000 lbs.	16,000 lbs.	5"	34 lbs.	250ft
1/2" 57MB-2	1/2"	0.875"	3,500 lbs.	14,000 lbs.	7"	43 lbs.	250ft
5/8" 57MB-2	5/8"	1.010"	2,750 lbs.	11,000 lbs.	8"	51 lbs.	250ft
3/4" 57MB-2	3/4"	1.158"	2,250 lbs.	9,000 lbs.	9.5"	61 lbs.	250ft
1" 57MB-2	1"	1.500"	2,000 lbs.	8,000 lbs.	12"	88 lbs.	250ft
