15B15-100RAF Dixon Non-Collapsible Fire & Utility Hose - Red - Coupled - Fem. x Male NST(NH) Expansion Ring Couplings (Aluminum) - 1-1/2" Hose Size - 1-1/2" Bowl Size - 100ft Length

15B15-100RAF Dixon Non-Collapsible Fire & Utility Hose - Red - Coupled - Fem. x Male NST(NH) Expansion Ring Couplings (Aluminum) - 1-1/2" Hose Size - 1-1/2" Bowl Size - 100ft Length

$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

Dixon Fire Fittings
Fire Hose - Non-Collapsible Hose - Fire and Utility Hose - Red - Coupled
Specifications for Variant SKU: 15B15-100RAF Dixon
Series: Fire Hose
Hose Color(s): Red
Internal Diameter: 1.5in
Tubing Construction: EPDM
Ends Configuration: 1-1/2in Female NST, 1-1/2in Male NST
Features:
  • Outer construction is designed to withstand abrasion.
  • Working pressure: 200 PSI at ambient temperature 70°F (21°C).
  • Burst pressure: 600 PSI at ambient temperature 70°F (21°C).
Part Number Hose Size Bowl Size Length Weight
(Lbs.)
Coupled with Female x Male NST(NH) Thread, Rocker Lug, Brass Expansion Ring Couplings
15B15-50RBF 1-1/2" 1-1/2" 50ft 25.4200
15B15-100RBF 1-1/2" 1-1/2" 100ft 100.0000
Coupled with Female x Male NST(NH) Thread, Rocker Lug, Aluminum Expansion Ring Couplings
15B15-50RAF 1-1/2" 1-1/2" 50ft 48.0000
15B15-100RAF 1-1/2" 1-1/2" 100ft 92.0000
Coupled with Female x Male NPSH Thread, Rocker Lug, Aluminum Expansion Ring Couplings
15B15-50RAS 1-1/2" 1-1/2" 50ft 53.0000
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
