20128C (20-128C) Midland Push-In Fitting - Bulkhead Union - 3/8" Tube OD - Composite Body

20128C by Midland | Push-In Fitting | Bulkhead Union | 3/8" Tube OD | Composite Body

Save $2.42 Save $2.42
$6.05
$6.05 - $6.05
$6.05
$3.63
$3.63 - $3.63
$3.63

Midland Industries
Brass Fitting - Composite Body Push-in Fitting - Bulkhead Union

The latest generation of composite material is used in the body construction in addition to brass on threaded components, and stainless steel on the tube gripper.

Inventory @ Manufacturers Warehouse: 105 Units
Specifications for Variant SKU: 20128C Midland
Shape (Orientation): Straight
Ends Configuration: 3/8in Push-to-Connect, 3/8in Push-to-Connect, Some Ends Match
Material(s): Plastic, Brass
Seal Material(s): NBR

SPECIFICATIONS

Fluid Admitted: Air Working Pressure Range: 0-150 PSI (10 BAR)
Min. Burst Pressure: 340 PSI (23 BAR) Working Temperature Range: 0°F ~160°F
Tolerance: +/- .02 on all dimensions.
Materials of Construcion
1 Body Composite Polyacetal (Hemopolymer, Copolymer)
2 Body Brass
3 Tube Release Acetal Resin
4 Retainer Brass
5 Gripper Ring Stainless Steel
6 Spacer Brass
7 O-Ring NBR 70
8 Threads Brass with White Sealant
Crossover Series:
PQ82P
Part Number Tube O.D. x Male NPT Approx. Weight
(Lbs.)
20127C
(20-127C)		 1/4" 0.04
20128C
(20-128C)		 3/8" 0.06
20129C
(20-129C)		 1/2" 0.10

Dimension Data can change without notice.

Midland Industries

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
