28683 (28-683) Midland Lincoln Interchange Pneumatic Male Coupler - 1/4" Male Pipe - 1/4" Body Size - Brass

28683 by Midland | Lincoln Interchange | Pneumatic Coupler | 1/4" Male Pipe | 1/4" Body Size | Brass

Save $3.82

$34.34

$34.34 - $34.34

$34.34

$30.52

$30.52 - $30.52

$30.52

Midland Industries
Lincoln Interchange Pneumatic Coupler

Inventory @ Manufacturers Warehouse: 40 Units

Quantity

Specifications for Variant SKU: 28683 Midland
Shape (Orientation):	Straight
Ends Configuration:	1/4in Male NPT, 1/4in Female Lincoln QD Interchange
Material(s):	Brass
Seal Material(s):	Buna-N/Nitrile Rubber

Features:
Couplers have brass bodies with steel sleeves, Acetal valves, 6 steel locking balls, Nitrile seal and stainless steel springs. Plugs are steel with green blue zinc plating. Manual style. Unique design includes long nose and short ball groove. Maximum working pressure is 250 PSI.

Couplers			Plugs
Brass Male Coupler			Steel Male Plug
Part Number	Thread Size	Body Size	Part Number	Thread Size	Body Size
-	-	-	28685 (28-685)	1/8"	1/4"
28683 (28-683)	1/4"	1/4"	28686 (28-686)	1/4"	1/4"

Brass/Steel Female Coupler			Steel Female Plug
Part Number	Thread Size	Body Size	Part Number	Thread Size	Body Size
28684 (28-684)	1/4"	1/4"	28687 (28-687)	1/4"	1/4"

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
