3/4" 4SH (EN856) Couplamatic Four Spiral Extra High Pressure Import Hydraulic Hose - 3/4" ID - Bulk

3/4" 4SH - EN856 by Couplamatic | Four Spiral Extra High Pressure | Import Hydraulic Hose | 3/4" ID | 50ft Bulk Length

Save $227.55

$568.88

$568.88 - $568.88

$568.88

$341.33

$341.33 - $341.33

$341.33

Couplamatic Systems Inc.
4 High Tensile Steel Spirals - 4SH Four Spiral Extra High Pressure Import Hydraulic Hose - 4SH (EN856)

Specifications for Variant SKU: 3/4" 4SH Couplamatic \| 50 \|
Series:	4SH Series
Hose Color(s):	Black
Dash Size:	-12
Internal Diameter:	0.75in
Outer Diameter:	1.268in
Applicable Specs & Approvals:	Applicable MSHA Standards
Compatible with the following Series:	6GC Series \| 4SH Series

DIN 4SH — Four Spiral

4SH Four Spiral Extra High Pressure Hydraulic Hose

DIN 4SH four-spiral hose for the very highest pressure hydraulic circuits, with a white layline and an MSHA approved abrasion and flame resistant cover.

1

What is this hose used for?

Very High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

Cover

Abrasion and Flame Resistant Black Cover, MSHA Approved, White Layline

Reinforcement

4 High Tensile Steel Spirals

Temperature

-40°F to +212°F (-40°C to +100°C)

Size Range

5/8" to 1-1/2"

3

What are the main product features?

Four high tensile steel spirals — extra high pressure hydraulic capability.
DIN 4SH construction — exceeds standard SAE spiral hose ratings.
White layline — clear identification on the equipment.
MSHA approved cover — abrasion and flame resistant black cover.
No skive required — terminates with 4SH Series and 6GC Series no-skive couplings.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
5/8" 4SH	5/8"	1.130"	6,090 lbs.	24,360 lbs.	9.5"	97 lbs.	Bulk
3/4" 4SH	3/4"	1.268"	6,090 lbs.	24,360 lbs.	11"	112 lbs.	Bulk
1" 4SH	1"	1.523"	5,510 lbs.	22,040 lbs.	13.5"	131 lbs.	Bulk
1-1/4" 4SH	1-1/4"	1.791"	5,075 lbs.	20,300 lbs.	18"	181 lbs.	Bulk
1-1/2" 4SH	1-1/2"	2.085"	4,205 lbs.	16,820 lbs.	22"	241 lbs.	Bulk

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
