3/4" R17 Couplamatic Import 3000 PSI Two Wire Hydraulic Hose (SAE 100R17) (Reduced OD) - 3/4" ID - 250ft

3/4" R17 by Couplamatic | Import 3000 PSI | Two Wire Hydraulic Hose | SAE 100R17 | Reduced OD | 3/4" ID | 250ft

Save $637.33

$1,593.33

$1,593.33 - $1,593.33

$1,593.33

$956.00

$956.00 - $956.00

$956.00

Couplamatic Systems Inc.
One or Two Wire Braids Hoses - R17 Import 3000 PSI Constant Working Pressure Hydraulic Hose - (SAE 100R17) (Reduced OD)

Package Quantity: 250 FT

Specifications for Variant SKU: 3/4" R17 Couplamatic \| 250 \|
Series:	R17 Series
Hose Color(s):	Black
Dash Size:	-12
Internal Diameter:	0.75in
Outer Diameter:	1.09in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R17
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series \| GW Series

SAE 100R17 — Reduced OD, ISO 18752

R17 Import 3000 PSI Constant Working Pressure Hydraulic Hose

Reduced outside diameter SAE 100R17 hose meeting ISO 18752, holding 3,000 PSI constant working pressure from 1/4" through 1".

1

What is this hose used for?

High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

SAE Rating

SAE 100R17

Cover

Abrasion and Flame Resistant Cover, MSHA Approved

Reinforcement

One (1/4"-1/2") or Two (5/8"-1") Wire Braids

Temperature

-40°F to +212°F (-40°C to +100°C)

3

What are the main product features?

3000 PSI constant working pressure — consistent rating across the full size range.
Reduced outside diameter — more hose fits through the same routing and clamps.
ISO 18752 compliant — meets the international performance standard.
One or two wire braids — one wire in 1/4"–1/2", two wire in 5/8"–1".
MSHA approved cover — abrasion and flame resistant.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" R17	1/4"	0.492"	3,000 lbs.	12,000 lbs.	2"	13 lbs.	500ft
3/8" R17	3/8"	0.649"	3,000 lbs.	12,000 lbs.	3"	19 lbs.	500ft
1/2" R17	1/2"	0.776"	3,000 lbs.	12,000 lbs.	4"	31 lbs.	350ft
5/8" R17	5/8"	0.937"	3,000 lbs.	12,000 lbs.	4"	41 lbs.	250ft
3/4" R17	3/4"	1.090"	3,000 lbs.	12,000 lbs.	5"	53 lbs.	250ft
1" R17	1"	1.405"	3,000 lbs.	12,000 lbs.	6"	82 lbs.	200ft

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.
