300-E-ALSWIV by Dixon Valve | Swivel Cam & Groove Adapter | Type E | 3" Adapter x 3" Hose Shank | Aluminum

Name: 300-E-ALSWIV by Dixon Valve | Swivel Cam & Groove Adapter | Type E | 3" Adapter x 3" Hose Shank | Aluminum
Brand: Dixon
SKU: 300-E-ALSWIV Dixon
Price: 141.88 USD
Availability: InStock

Save $94.59

$236.47

$236.47 - $236.47

$236.47

$141.88

$141.88 - $141.88

$141.88

Dixon Valve
Swivel Coupling Cam & Groove | Type E Adapter | Adapter x Hose Shank

Live swivel is capable of 360-degree rotation under pressure.

Specifications for Variant SKU: 300-E-ALSWIV Dixon
Shape (Orientation):	Straight
Cam Type:	Type E
Ends Configuration:	3in Male Cam & Groove, 3in Hose Barb
Material(s):	Aluminum
Special Properties:	Swivel

Features:
Nitrile rubber X-ring seal for reduced friction and high stability in dynamic applications. Gasket: nitrile rubber.

356T6 Aluminum Part Number	316 Stainless Steel Part Number	Size	Maximum Operating Pressure
200-E-ALSWIV	200-E-SSSWIV	2"	250 PSI
300-E-ALSWIV	300-E-SSSWIV	3"	125 PSI 150 PSI with King Crimp ferrule system
400-E-ALSWIV	400-E-SSSWIV	4"	100 PSI 150 PSI with King Crimp ferrule system
