3130 06 10 by Parker | Legris | 6 mm Tamper Proof Safety Clip | White | Polymer

3130 06 10 by Parker | Legris | 6 mm Tamper Proof Safety Clip | White | Polymer | Pack of 100

Save $4.64 Save $4.64
$71.31
$71.31 - $71.31
$71.31
$66.67
$66.67 - $66.67
$66.67

by Parker Hannifin
LF 6100® Push-In Fittings:3130 Tamper-Proof Safety Clip

Package Quantity: 100 Units

Specifications for Variant SKU: 3130 06 10 Parker | 100 |
Series: 3130 Series
Shape (Orientation): No Orientation
Material(s): Polymer
Special Properties: Silicone Free
Technical Characteristics:
  • Compatible Ranges: LF3000®, LIQUIfit®
  • Working Temperature: -30°C to +95°C
  • Component Materials: Tamper-proof safety clip, release button cover, clip: technical polymer
Advantages:
  • Safety: Protection of operators and equipment
  • Prevents accidental disconnection
  • Identification: 6 color coding for fluid circuit identification
  • Easy disconnection with dismounting tool
Part Number ØD H K Kg
3130 06 10 6 mm 7.8 mm 3.1 mm .001 Kg
3130 10 10 10 mm 10.8 mm 4.2 mm .002 Kg
3130 56 10 1/4" 8 mm 3 mm .001 Kg
3130 12 10 12 mm 12.5 mm 5.1 mm .003 Kg
