3329 00 03 by Parker | Legris Modular Plug-In Connectors | M58x1.5 Screw Cap | 12 Outlets | 70 mm Length | Straight | Polymer

Save $3.27

$35.92

$35.92 - $35.92

$35.92

$32.65

$32.65 - $32.65

$32.65

by Parker Hannifin
LF 3000 ® Push-In Fittings / Modular Plug-In Connectors:3329 Multi-Connector Screw Cap

Quantity

Specifications for Variant SKU: 3329 00 03 Parker
Series:	3329 Series
Shape (Orientation):	Straight
Material(s):	Polymer
Special Properties:	Silicone Free

Technical Characteristics:	Compatible Fluids: Compressed air Working Pressure: Vacuum to 10 bar Working Temperature: -20°C to +80°C
Advantages:	3 types of solutions: in-line, panel-mounted or DIN rail connector Minimized connection space Prevents incorrect assembly Customized multi-connectors upon request
Regulations:	ISO 14743 PED RoHS REACH
Component Materials:	Panel-mounted: Zinc-Plated Steel, Technical Polymer In-Line: Aluminum, Technical Polymer DIN Rail: Technical Polymer


Part Number	C	Number of Outlets	G	G1	L	Kg
3329 00 02	M40x1.5	4-7	35 mm	50 mm	55 mm	.062 Kg
3329 00 03	M58x1.5	12	34 mm	70 mm	70 mm	.139 Kg
3329 00 04	M65x1.5	12	2.01"	-	3.46"	.122 Kg

‘

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
