3329 00 04 by Parker | Legris Modular Plug-In Connectors | M65x1.5 Screw Cap | 12 Outlets | 3.46" Length | Straight | Polymer

Save $3.48

$38.25

$38.25 - $38.25

$38.25

$34.77

$34.77 - $34.77

$34.77

by Parker Hannifin
LF 3000 ® Push-In Fittings / Modular Plug-In Connectors:3329 Multi-Connector Screw Cap

Quantity

Specifications for Variant SKU: 3329 00 04 Parker
Brand:	LF 3000®
Series:	3329 Series
Shape (Orientation):	Straight
Material(s):	Polymer
Special Properties:	Silicone Free, Corrosion Resistance, Chemical Resistance

Technical Characteristics:	Compatible Fluids: Compressed air Working Pressure: Vacuum to 10 bar Working Temperature: -20°C to +80°C
Advantages:	3 types of solutions: in-line, panel-mounted or DIN rail connector Minimized connection space Prevents incorrect assembly Customized multi-connectors upon request
Regulations:	ISO 14743 PED RoHS REACH
Component Materials:	Panel-mounted: Zinc-Plated Steel, Technical Polymer In-Line: Aluminum, Technical Polymer DIN Rail: Technical Polymer


Part Number	C	Number of Outlets	G	G1	L	Kg
3329 00 02	M40x1.5	4-7	35 mm	50 mm	55 mm	.062 Kg
3329 00 03	M58x1.5	12	34 mm	70 mm	70 mm	.139 Kg
3329 00 04	M65x1.5	12	2.01"	-	3.46"	.122 Kg

‘
