338978 by Alemite | FCS Fluid Solenoid Valve | 1/2" Female NPTF Inlet/Outlet | 3000 PSI | up to 6 GPM | Includes Manual Override and Screen

338978 by Alemite | FCS Fluid Solenoid Valve | 1/2" Female NPTF Inlet/Outlet | 3000 PSI | up to 6 GPM | Includes Manual Override and Screen

Save $100.84 Save $100.84
$352.93
$352.93 - $352.93
$352.93
$252.09
$252.09 - $252.09
$252.09

PRODUCT DESCRIPTION

Alemite Fluid Management System - Accessories - Alemite FCS Accessories
Specifications for Variant SKU: 338978 Alemite
Applications:
  • Alemite Fluid Management Systems provide simple and cost effective fluid use management and reporting. Simple user keypad interface controls solenoid valves, which allow dispensing of fluids. Meters mounted in line with each hose reel provide data to the control system.
Features:
  • NA



Part Number Description Information
339005 Pulse Meter (Oil) 1/2" NPTF(f) inlet/outlet, max operating pressure 1,500 psi, 0.25 - 8 gpm
338315 Fluid Solenoid Valve with connector 1/2" NPTF(f) inlet/outlet, max operating pressure 3,000 psi, up to 6 gpm; includes manual override and screen
338978 Fluid Solenoid Valve 1/2" NPTF(f) inlet/outlet, max operating pressure 3,000 psi, up to 6 gpm; includes manual override and screen
339317 Air Solenoid 3/8" NPTF(f) inlet/outlet, 5 - 150 psi operating pressure, 10 watts
343025 Connector, Solenoid Valve, Prewired Prewired with 3' pigtail
339277-1 Pressure Relief Valve 900 psi max, 1 per pump
339277-2 Pressure Relief Valve 1,400 psi max, 1 per pump
343027 Printer Adapter Cable 30'
339318 Station Ready Lamp 24VDC power
339276 Pressure Relief Valve Installation Kit Includes 3' connecting hose and 2 tee reducing branches
343030-50 50' Cable 50' Cable with FCS plug on one end; bare leads on other end
343030-100 100' Cable 100' Cable with FCS plug on one end; bare leads on other end
343030-500 500' Cable 500' Cable with FCS plug on one end; bare leads on other end



Alemite | SKF

Alemite | SKF

Alemite products have quietly been a major part of many of the world’s
essential industries. Manufacturing, construction, agriculture, automotive,
pulp and paper, aircraft maintenance, marine and mining industries have
benefitted from the innovations introduced since its founding in 1918.
