364PLP-16M-12M by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Tube to Tube Fittings | 16mm to 12mm Unequal Union | Tee | Glass-Reinforced Nylon | Pack of 5

Save $94.57

$236.43

$236.43 - $236.43

$236.43

$141.86

$141.86 - $141.86

$141.86

by Parker Hannifin
Push-to-Connect Fittings:364PLP Unequal Union Tee

Package Quantity: 5 Units

Specifications for Variant SKU: 364PLP-16M-12M Parker \| 5 \|
Series:	364PLP Series
Shape (Orientation):	Tee
Material(s):	Glass-Reinforced Nylon
Special Properties:	Corrosion Resistance, Chemical Resistance, Silicone Free

Product Features:	Stainless steel grab ring Glass-reinforced nylon 6.6 body Nitrile D-seal Nylon release button Corrosion and chemical resistance NPT, BSPT, BSPP, and metric threads Silicone Free
Markets:	Pneumatic Industrial Robotic Automation Printing Packaging Textile
Compatible Media:	Compressed Air Inert Gases Vacuum
Pressure Range:	Up to 290 PSI (19.9 bar) depending on tubing Up to 260 PSI (17.9 bar) depending on tubing (3/16” size only)
Temperature Range:	-4° to +175° F (-20° to +79.4° C) 5° to +155° F (-15° to +68.3° C) (3/16” size only)
Vacuum Rating:	28" Hg
Compatible Tubing:	Semi-rigid nylon Polyurethane 95 Durometer Shore A* Nylon Fluoropolymer Polyethylene


Part Number	Tube Size 1	Tube Size 2	H	L/2
364PLP-4M-6M	4 mm	6 mm	22.5 mm	17.5 mm
364PLP-6M-4M	6 mm	4 mm	22.5 mm	17.5 mm
364PLP-6M-8M	6 mm	8 mm	29.5 mm	23.0 mm
364PLP-8M-6M	8 mm	6 mm	29.5 mm	23.0 mm
364PLP-8M-10M	8 mm	10 mm	34.5 mm	26.5 mm
364PLP-10M-12M	10 mm	12 mm	34.5 mm	26.5 mm
364PLP-10M-8M	10 mm	8 mm	40.5 mm	31.0 mm
364PLP-12M-10M	12 mm	10 mm	40.5 mm	31.0 mm
364PLP-14M-8M	14 mm	8 mm	46.0 mm	35.5 mm
364PLP-16M-12M	16 mm	12 mm	39.0 mm	N/A
