5750808K by Dixon Valve | Lok-On (Push-On) Garden Hose Fitting Complete Set | 3/4" Female GHT x 3/4" Male GHT x 1/2" Hose ID | Brass

Name: 5750808K by Dixon Valve | Lok-On (Push-On) Garden Hose Fitting Complete Set | 3/4" Female GHT x 3/4" Male GHT x 1/2" Hose ID | Brass
Brand: Dixon
SKU: 5750808K Dixon
Price: 16.93 USD
Availability: InStock

Save $11.29

$28.22

$28.22 - $28.22

$28.22

$16.93

$16.93 - $16.93

$16.93

Dixon Valve
Lok-On (Push-On) Garden Hose Fitting Complete Set | Female GHT x Male GHT x Hose Barb

Intended for use with Lok-On (push-on style) hose only.

Specifications for Variant SKU: 5750808K Dixon
Series:	575 Series
Shape (Orientation):	Straight
Ends Configuration:	3/4in Male GHT, 3/4in Female GHT, 1/2in Push-On Hose Barb
Material(s):	Brass

Features:
No hose clamps or ferrules are needed for installation. Properly grips push-on hose only when pushed all the way in, with the cut end of the hose completely concealed by the plastic cap. Not assembled.
Material:
Brass Yellow Plastic Cap Washer included
Specifications:
Temperature Range: 34°F to 150°F Pressure Rating: 150 PSI
Safety Notes:
Dixon push-on fittings are intended for use with Lok-On (push-on style) hose only. Caution: Push-on fittings will properly grip push-on hose only when pushed all the way in, with the cut end of the hose completely concealed by the plastic cap.
Installation:
Assembly Instructions: 1. Trim hose end with smooth square cut. 2. Lubricate either push-on fitting, hose or both. 3. Insert push-on fitting into hose until first barb is in hose. 4. Place end of fitting against a flat object (bench, wall, etc.) and grip the hose one inch from end. Push with a steady force until end of hose is covered by yellow plastic cap. Disassembly Instructions: 1. Leaving push-on fitting in place, make a 1" cut in the hose along the barbed end of the fitting. Note: Be careful not to nick barbs when cutting the hose. 2. With firm grip on hose, give a sharp downward pull to release the fitting from the hose.

Part Number	Previous Part Number	Hose I.D.	Female GHT x Male GHT Thread
5750808K	575-0808	1/2"	3/4"
5751010K	575-1010	5/8"	3/4"
5751212K	575-1212	3/4"	3/4"

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
