60142540 (25X40A) by PT-Coupling | Reducing Cam & Groove Adapter | Type A | 2-1/2" Adapter x 4" Female NPT | Aluminum

Name: 60142540 (25X40A) by PT-Coupling | Reducing Cam & Groove Adapter | Type A | 2-1/2" Adapter x 4" Female NPT | Aluminum
Brand: PT-Coupling
SKU: 60142540 PT-Coupling
Price: 84.07 USD
Availability: InStock

Save $49.61

$133.68

$133.68 - $133.68

$133.68

$84.07

$84.07 - $84.07

$84.07

PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type A | Adapter x Female NPT | Aluminum

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 60142540 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Type A
Ends Configuration:	2-1/2in Male Cam & Groove, 4in Female NPT
Material(s):	Aluminum

Features & Applications:
Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance. Use with water, hydraulic oil, coolants, gasoline, and petroleum products. Made in the USA

Part Name	Item #	Adapter Size	Female NPT Threads	Max. Allowable Working Press. (PSI)*
07X10A	60220710	3/4"	1"	250 PSI
10X15A	60141015	1"	1-1/2"	250 PSI
15X10A	60141510	1-1/2"	1"	250 PSI
15X20A	60141520	1-1/2"	2"	250 PSI
20X15A	60142015	2"	1-1/2"	250 PSI
20X25A	60142025	2"	2-1/2"	200 PSI
20X30A	60142030	2"	3"	200 PSI
25X15A	60142515	2-1/2"	1-1/2"	200 PSI
25X20A	60142520	2-1/2"	2"	200 PSI
25X30A	60142530	2-1/2"	3"	200 PSI
25X40A	60142540	2-1/2"	4"	150 PSI
30X20A	60143020	3"	2"	200 PSI
30X25A	60143025	3"	2-1/2"	200 PSI
30X40A	60143040	3"	4"	150 PSI
40X25A	60144025	4"	2-1/2"	150 PSI
40X30A	60144030	4"	3"	150 PSI
40X50A	60144050	4"	5"	75 PSI
50X30A	60145030	5"	3"	75 PSI

** Denotes parts are produced as a welded fabrication.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
