6018000001 (20X15B) by PT-Coupling | Reducing Cam & Groove Adapter | Type B | 2" Coupler x 1-1/2" Male NPT | Aluminum/HB | Buna-N Seal

Save $26.22

$70.65

$70.65 - $70.65

$70.65

$44.43

$44.43 - $44.43

$44.43

PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type B | Adapter x Male NPT | Aluminum/HB | Buna-N Seal

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 6018000001 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Type B
Ends Configuration:	2in Female Cam & Groove, 1-1/2in Male NPT
Material(s):	Aluminum
Seal Material(s):	Buna-N/Nitrile

Features & Applications:
HB cam arms are made of Brass. Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance. Use with water, hydraulic oil, coolants, gasoline, and petroleum products. Made in the USA

Part Name	Item #	Coupler Size	Male NPT Threads	Max. Allowable Working Press. (PSI)*
15X10B	6018000009	1-1/2"	1"	250 PSI
20X15B	6018000001	2"	1-1/2"	250 PSI
20X30B	6018000002	2"	3"	200 PSI
25X20B	6018000003	2-1/2"	2"	200 PSI
25X30B	6018000004	2-1/2"	3"	200 PSI
30X20B	6018000005	3"	2"	200 PSI
30X25B	6018000006	3"	2-1/2"	200 PSI
30X40B	6018000103	3"	4"	150 PSI
40X20B	6018000007	4"	2"	150 PSI
40X30B	6018000008	4"	3"	150 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
