6027000045 (30CX30C) by PT-Coupling | Cam & Groove Adapter | Spool Coupler | Type CXC | 3" Coupler x 3" Coupler | Aluminum/HB | Buna-N Seal

6027000045 (30CX30C) by PT-Coupling | Cam & Groove Coupler | Spool Coupler | Type CXC | 3" Coupler x 3" Coupler | Aluminum/HB | Buna-N Seal

Save $40.46

$108.98

$108.98 - $108.98

$108.98

$68.52

$68.52 - $68.52

$68.52

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 6027000045 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Other
Ends Configuration:	3in Female Cam & Groove, 3in Female Cam & Groove, Some Ends Match
Material(s):	Aluminum
Seal Material(s):	Buna-N/Nitrile

Features & Applications:
HB cam arms are made of Brass. Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance. Use with water, hydraulic oil, coolants, gasoline, and petroleum products. Made in the USA

Part Name	Item #	Coupler Size	Coupler Size	Max. Allowable Working Press. (PSI)*
10CX10C	6027000048	1"	1"	250 PSI
12CX12C	6027000049	1-1/4"	1-1/4"	250 PSI
15CX15C	6027000042	1-1/2"	1-1/2"	250 PSI
20CX20C	6027000043	2"	2"	250 PSI
25CX25C	6027000050	2-1/2"	2-1/2"	200 PSI
30CX20C	6027000044	3"	2"	200 PSI
30CX30C	6027000045	3"	3"	200 PSI
40CX30C	6027000046	4"	3"	150 PSI
40CX40C	6027000047	4"	4"	150 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
