6452600H (PF60AHD) by PT-Coupling | Heavy Duty Cam & Groove Adapter | Type PFA | 6" Adapter x 6" 150# Pipe Flange | 316 Stainless Steel

Name: 6452600H (PF60AHD) by PT-Coupling | Heavy Duty Cam & Groove Adapter | Type PFA | 6" Adapter x 6" 150# Pipe Flange | 316 Stainless Steel
Brand: PT-Coupling
SKU: 6452600H PT-Coupling
Price: 1415.17 USD
Availability: InStock

Save $835.43

$2,250.60

$2,250.60 - $2,250.60

$2,250.60

$1,415.17

$1,415.17 - $1,415.17

$1,415.17

PT Coupling
Heavy Duty Cam & Groove (Camlock) Adapter | Type PFA | Adapter x 150# Pipe Flange | 316 Stainless Steel

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 6452600H PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Other
Ends Configuration:	6in Male Cam & Groove, 6in 150# Flange
Material(s):	316 Stainless Steel

Features & Applications:
Excellent corrosion-resistant material that provides high strength at high temperatures, helps prevent contamination of product being transported, maintains cleanliness and retains a lustrous appearance. Harder than brass. Ideal for use with salt water, waste water, and many chemicals; can also be used with hydraulic oil and coolants. Pipe Flange bolt pattern conforms to ANSI B16.5 Class 150. Stainless Steel and Carbon Steel Flanges are raised face. Other materials are supplied with flat face flanges. Made in the USA

Part Name	Item #	Heavy Duty Adapter Size	Flange Size	Max. Allowable Working Press. (PSI)*
PF40AHD	64524000H	4"	4"	150 PSI
PF60AHD	6452600H	6"	6"	75 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
