76542000 (PF20C) by PT-Coupling | Corrosion Resistant Cam & Groove Adapter | Type PFC | 2" Coupler x 2" 150# Pipe Flange | Hastelloy C | Buna-N Seal

76542000 (PF20C) by PT-Coupling | Corrosion Resistant Cam & Groove Coupler | Type PFC | 2" Coupler x 2" 150# Pipe Flange | Hastelloy C | Buna-N Seal

Save $502.16

$1,352.80

$1,352.80 - $1,352.80

$1,352.80

$850.64

$850.64 - $850.64

$850.64

PT Coupling
Corrosion Resistant Cam & Groove (Camlock) Adapter | Type PFC | Coupler x 150# Pipe Flange | Hastelloy C | Buna-N Seal

These corrosion resistant cam & groove couplings are designed for acid applications in highly corrosive media including hydrochloric acid and sulfuric acid.

Made in the USA

Specifications for Variant SKU: 76542000 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Other
Ends Configuration:	2in Female Cam & Groove, 2in 150# Flange
Material(s):	Hastelloy C
Seal Material(s):	Buna-N/Nitrile

Features & Applications:
These corrosion resistant cam & groove couplings are designed for acid applications in highly corrosive media including hydrochloric acid and sulfuric acid. Made in the USA

Part Name	Item #	Coupler Size	Pipe Flange Size	Max. Allowable Working Press. (PSI)*
PF20C	76542000**	2"	2"	250 PSI
PF40C	76544000RF	4"	4"	150 PSI

** Parts have a raised face flange
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
