7899 00 17 by Parker | Legris Quick Exhaust Valve | 3/8" Female BSPP Thread | 44.5mm Length | 90° Elbow | 316L Stainless Steel

Save $119.43

$298.58

$298.58 - $298.58

$298.58

$179.15

$179.15 - $179.15

$179.15

by Parker Hannifin
Metal Quick Exhaust Valves:7899 Quick Exhaust Valve, Female BSPP Thread

Specifications for Variant SKU: 7899 00 17 Parker
Series:	7899 Series
Shape (Orientation):	90° Elbow
Material(s):	316L Stainless Steel
Seal Material(s):	FKM
Special Properties:	Silicone Free

Technical Characteristics:	Compatible Fluids: Compressed air Working Pressure: 7970: 0.7 to 10 bar 7971 and 7899: 2 to 10 bar Working Temperature: 7970: -20°C to +70°C 7971: -10°C to +70°C 7899: Threads G1/8 and G1/4: -10°C to +120°C Threads G1/8 and G1/4: -20°C to +80°C
Advantages:	Cycle time reduction: increased return speed Exhaust silencer integrated and 360° orientation available on some versions
Regulations:	RoHS REACH PED
Component Materials:	Integrated silencer: Stainless Steel (Model 7971) Lip Seals: 7970-7971: Polyurethane elastomer 7899: - G1/8 and G1/4 FKM - G3/8 and G1, Polyurethane Body: Model 7970: Nickel-Plated Brass Model 7971: Anodized Aluminum Model 7899: Stainless Steel


Part Number	Diameter Nominal (DN)	C	F	F1	H	L	L1	L2	Kg
7899 00 10	7 mm	1/8"	17 mm	22 mm	31.5 mm	37.5 mm	21 mm	16.5 mm	.096 Kg
7899 00 13	7 mm	1/4"	17 mm	22 mm	31.5 mm	37.5 mm	21 mm	16.5 mm	.083 Kg
7899 00 17	9 mm	3/8"	22 mm	26 mm	37 mm	44.5 mm	25.5 mm	19 mm	.140 Kg
7899 00 21	12 mm	1/2"	27 mm	32 mm	45 mm	54 mm	31 mm	23 mm	.235 Kg
