8072-B by Alemite | Diesel Exhaust Fluid Hose Reel | Max Pressure: 300 PSI | Delivery Hose Specification: 1/2 ID x 50ft | Hose Reel Inlet Female: 1/2" BSPP | Delivery Hose Outlet Male: 1/2" BSPP | Maroon

8072-B by Alemite | Diesel Exhaust Fluid Hose Reel | Max Pressure: 300 PSI | Delivery Hose Specification: 1/2 ID x 50ft | Hose Reel Inlet Female: 1/2" BSPP | Delivery Hose Outlet Male: 1/2" BSPP | Maroon

Save $156.03 Save $156.03
$1,404.23
$1,404.23 - $1,404.23
$1,404.23
$1,248.20
$1,248.20 - $1,248.20
$1,248.20

PRODUCT DESCRIPTION

Alemite Diesel Exhaust Fluid - Hose Reels
Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: 8072-B Alemite
Applications:
  • Alemite's heavy duty hose reels deliver Diesel Exhaust Fluid (AUS32, Aqueous Urea Solution) in two reel capacities (30-50 ft.). Specifically designed for DEF systems, the reels are engineered to perform better, last longer and are safer to maintain and operate. Reels can be mounted overhead, on a wall, floor or tank.
Features:
    • Temperature range: -15 to +250° F (-26 to +151° C)
    • Hose spring and bearings are factory lubricated and require no further lubrication
    • Easily adjustable guide arm
    • Spring powered and self-retracting
    • Ratchet type latch
    • Gasket-sealed spring case
    • Durable powder coat finish
    • Balanced-pressure swivel
    • Stainless steel shaft and swivel sealed with flouroelastomer o-rings
    • Heavy-gauge steel construction
    • Adjustable hose stop


    • INCLUDED ITEMS (8072-A and 8072-B):
    • Delivery Hose
    • Hose Stop


  • ITEMS SOLD SEPARATELY:
  • 343143-2 - 2' connecting DEF Hose
  • 343196 - Stainless Steel 1/2" BSPP female x 3/4" BSPP male adapter
  • 393539-157 - 30' Goodyear DEF Hose Assembly
  • 393539-158 - 50' Goodyear DEF Hose Assembly

Part Number Max Pressure Delivery Hose
Specification		 Weight Hose Reel
Inlet Female		 Delivery Hose
Outlet Male
8072-B 300 PSI (17 bar) 1/2 ID x 30' (13 mm x 9 m) 50.0 lbs (22.7 kg) 1/2" BSPP 1/2" BSPP
