944110 (944-110) Midland Forged Mini Ball Valve - 3/8" Male Pipe x 3/8" Male Pipe - Brass

944110 by Midland | Forged Mini Ball Valve | 3/8" Male Pipe x 3/8" Male Pipe | Brass

Save $5.14 Save $5.14
$12.85
$12.85 - $12.85
$12.85
$7.71
$7.71 - $7.71
$7.71

Midland Industries
Forged Mini Ball Valve - Male Pipe x Male Pipe - Brass

200 WOG working pressure

Inventory @ Manufacturers Warehouse: 12 Units
Specifications for Variant SKU: 944110 Midland
Shape (Orientation): Straight
Ends Configuration: 3/8in Male NPT, 3/8in Male NPT
Material(s): Brass
Seal Material(s): NBR
Features:
  • Temp rating: -20°F - 250°F
  • Generic Handles
  • Not lead free
Construction:
  • 180° operational handle
  • Blow out proof stem
  • Stem with double "O" Rings
Number Part Name Material QTY
1 Nut Steel 1
2 Handle Steel 1
3 Cover PVC 1
4 O-Ring NBR 2
5 Stem Brass 1
6 Body Brass 1
7 Seat Teflon 2
8 Ball Disc Brass 1
9 End Plug Brass 1
Part Number Size A B C D
944107
(944-107)		 1/8" 1.70" 2.94" 0.65" 1.42"
944109
(944-109)		 1/4" 1.25" 2.66" 0.65" 1.42"
944110
(944-110)		 3/8" 1.90" 2.98" 0.73" 1.42"

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
