B-3009-3 Breco by Foster | W Series | 3/8" Cap | Steel

B-3009-3 Breco by Foster | W Series | 3/8" Cap | Steel

Save $1.15 Save $1.15
$2.88
$2.88 - $2.88
$2.88
$1.73
$1.73 - $1.73
$1.73

Foster Quick Disconnects - 3/8" Dust Plugs & Dust Caps - Breco
Specifications for Variant SKU: B-3009-3 ZSi-Foster
Brand: Breco
Series: W Series
Material(s): Steel
W Series [High Pressure Coupling, Enerpac Interchange]
Features:
  • Machined from solid steel bar stock for durability
  • Threaded sleeve locking mechanism mates with plug threads for secure manual connection
  • Chrome alloy balls used for valving; spring-loaded for positive sealing
  • Metal-to-metal seal between ball and coined seat
  • Polyurethane body seal resists high pressure extrusion
  • Threaded valve retainer ensures positive valve alignment
 Applications:
The "W" Series couplings, with threaded union locking and precision ball-type check valves, are ideal for extreme high-pressure applications such as portable hydraulic rams.
Specifications:
Size Rated Pressure (psig) Static Temperature Range (std seals)
1/4", 3/8" 10,000 -10° to +250°F
Note:
Protective dust plugs and caps are essential to prolong the life of a quick coupling. Every hydraulic quick coupling purchase should include proper dust plug and cap selection.
Dust Plug Part No. (Steel) Dust Cap Part No. (Steel) Size
B-3005-3 B-3009-3 3/8"
