BN25F Dixon Brass Plain Hose Nozzle - 2-1/2" Female NST(NH) - 12" Length

BN25F Dixon Brass Plain Hose Nozzle - 2-1/2" Female NST(NH) - 12" Length

Name: BN25F Dixon Brass Plain Hose Nozzle - 2-1/2" Female NST(NH) - 12" Length
Brand: Dixon
SKU: BN25F Dixon
Price: 136.51 USD
Availability: InStock

Save $91.01

$227.52

$227.52 - $227.52

$227.52

$136.51

$136.51 - $136.51

$136.51

Dixon Fire Fittings
Fire Nozzles - Plain Hose Nozzle - Brass

For use with water only.

Specifications for Variant SKU: BN25F Dixon
Shape (Orientation):	Straight
Material(s):	Brass

Features:
Satin finish Maximum operating pressure: 100 PSI (water only) at 70°F (21°C)

Part Number	Female Thread	Length	Orifice	Old Part #	Replacement Gasket	Weight (Lbs.)
BN6	3/4" Female GHT	6"	1/4"	500SN6	KRW5	0.3500
BN7	3/4" Female NPSH	6"	1/4"	-	KRW5	0.3500
BN10	1" Female NPSH	8"	5/16"	-	KRW10	0.4500
BN12	1-1/4" Female NPSH	10"	3/8"	-	KRW15	1.1200
BN15	1-1/2" Female NPSH	10"	1/2"	-	KRW20	0.9100
BN20	2" Female NPSH	12"	9/16"	-	SW200	1.5600
BN25	2-1/2" Female NPSH	12"	1"	-	KRW35	2.8200
BN10F	1" Female NST (NH)	8"	5/16"	-	SW100F	0.5900
BN15F	1-1/2" Female NST (NH)	10"	1/2"	-	SW150	0.9300
BN25F	2-1/2" Female NST (NH)	12"	1"	-	SW250	2.5500
BN15NYFD	1-1/2" Female NYFD	10"	1/2"	-	SW150	1.4300
BN25NYFD	2-1/2" Female NYFD	12"	1"	-	SW250	2.7100

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
