BV2HG-25011-EP Dixon Valve 2-1/2" Electrically Actuated Two-Piece Stainless Ball Valve - Seat: RTFE - 110VAC with Manual Override

BV2HG-25011-EP Dixon Valve 2-1/2" Electrically Actuated Two-Piece Stainless Ball Valve - Seat: RTFE - 110VAC with Manual Override

$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

Dixon Sanitary Valves
Electrically Actuated Two-Piece Stainless Ball Valve - 110VAC with Manual Override - 316 Stainless Steel

Seat: RTFE
Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: BV2HG-25011-EP Dixon
Shape (Orientation): Straight
Material(s): Stainless Steel
Features:
  • Valve has RTFE seats and seals, a blow-out proof stem, and a ISO 5211 mounting pad.
  • Electric actuator has lightweight powder coated aluminum alloy housing and is NEMA 4/4X waterproof and dustproof.
  • Actuator features high alloy steel gear train, H-insulation class, visual position indication, and a space heater.
  • Temperature Range:
    • Valve: -40°F to 325°F (-40°C to 163°C)
    • Actuator: -41°F to 140°F (-41°C to 60°C)
Specifications:
  • ISO 9001, CS, CE and CSA-C US
  • RoHS compliant
Safety Notes:
  • Even though there are torque safety factors built into our automated ball valve packages, actual service conditions must also be considered when selecting the proper product for the appropriate application.
  • Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other viscous fluids can have a dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators may be required. Please consult Dixon when dealing with these types of applications.
Part Number Size Pressure Rating
BV2HG-25011-EP 2-1/2" 800 PSI WOG
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
