BVGT4-3/4C by Parker | Standard In-Line Ball Valve w/ Butterfly Handle | 3/4" Female BSPP Thread | 31 mm Hex | 54 mm Length | Straight | Nickel-Plated Brass

BVGT4-3/4C by Parker | Standard In-Line Ball Valve w/ Butterfly Handle | 3/4" Female BSPP Thread | 31 mm Hex | 54 mm Length | Straight | Nickel-Plated Brass

Save $15.65 Save $15.65
$106.48
$106.48 - $106.48
$106.48
$90.83
$90.83 - $90.83
$90.83

by Parker Hannifin
Standard Series:BVGT4-C 2/2 Standard In-Line Ball Valve, Female BSPP Thread, Butterfly Handle
Specifications for Variant SKU: BVGT4-3/4C Parker
Shape (Orientation): Straight
Material(s): Nickel-Plated Brass
Seal Material(s): PTFE, Rubber
Special Properties: Silicone Free, Corrosion Resistance
Technical Characteristics:
  • Model: Standard and Lockable Series
  • Compatible Fluids: Compressed air
  • Working Pressure: 0 to 40 bar up to 2"
    0 to 30 bar up to 2"
    expected BVG4P-LOCK and BVG4-LOCK: 0 to 14 bar
  • Working Temperature: -20°C to +170°C
    excepted BVG3P-LOCK: -10°C to +100°C
Advantages:
  • Long or butterfly handle
  • Full fluid flow
  • A lockable version for safety in use
  • Corrosion resistance thanks to chemical nickel plating
Regulations:
  • PED
  • RoHS
  • REACH
Component Materials:
  • Locking System: Treated Steel
  • Stem seal: FPM o-rings
  • Seat seals: PTFE
  • Long Lever: Geomet plated steel
  • Compact Series Lever: Technical Polymer
  • Butterfly Lever: Aluminum
  • Locking nut and Locking screw: Zinc plated steel
  • Stem: Nickel-Plated Brass
  • Body: Nickel plated or chromium-plated shot blasted brass
  • Ball: Chromium-plated brass
Part Number Diameter Nominal (DN) C E F G H L M Kg
BVGT4-3/4C 20 mm 3/4" 12 mm 31 mm 39 mm 49 mm 54 mm 50 mm .265 Kg

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
