CS35-8X8 Couplamatic VARI-CRIMP Coupling - BSPT - British Standard Tapered - Male Pipe Solid - 1/2" Hose ID - R-1/2-14 Thread - 1/2" BSPT (Old Part Number: 8T58V)

CS35-8X8 by Couplamatic | VARI-CRIMP Coupling | 1/2" Hose ID x R-1/2-14 Thread Male Pipe Solid | 1/2" BSPT | Straight | Trivalent Zinc Plating | Replaces: 8T58V

Save $3.83 Save $3.83
$9.57
$9.57 - $9.57
$9.57
$5.74
$5.74 - $5.74
$5.74

Couplamatic Systems Inc.
Vari-Crimp Couplings - BSPT - British Standard Tapered - Male Pipe Solid
Specifications for Variant SKU: CS35-8X8 Couplamatic
Series: VARI-CRIMP Series
Shape (Orientation): Straight
Ends Configuration: 1/2in Male BSPT, 1/2in Hose Barb
Material(s): Steel
Compatible with the following Series: 56MB-1 Series  |   57MB-2 Series  |   56MB-2 Series  |   HPI Series  |   HPIII Series  |   2SN Series  |   R16 Series  |   DH16 Series  |   DHEX16 Series  |   R17 Series  |   R17R Series  |   WDH17 Series  |   3319A Series
Description:
  • The Vari-Crimp coupling is compatible with virtually all Crimp Machines. Trivalent Zinc Plating.
  • R. as part of thread size is ISO designation for tapered thread
Part Number Hose ID BSPT Size Thread Size Hex Size PreviousPart Number Cross Reference Part Numbers
Dayco HY Parker HY Weatherhead U
CS35-4X4 1/4" 1/4" R-1/4-19 5/8" 4T54V HY04-04BT 1UTHY-4-4 04U-154
CS35-6X6 3/8" 3/8" R-3/8-19 3/4" 6T56V HY06-06BT 1UTHY-6-6 06U-156
CS35-8X8 1/2" 1/2" R-1/2-14 7/8" 8T58V HY08-08BT 1UTHY-8-8 08U-158
CS21-12X12 3/4" 3/4" R-3/4-14 1-1/8" 12T62V HY12-12BT - 12U-162

The cross reference is for thread identification and hose inside diameter only. Exact dimensions of the couplings may vary from manufacturer to manufacturer. Please check hose cut off factor, tube length, and tube drop carefully.
