CSS100-7CS by Dixon Valve | Short Crimp Sleeve | 1" Hose ID | Hose OD Range: from 1-37/64" to 1-40/64" | Carbon Steel

CSS100-7CS by Dixon Valve | Short Crimp Sleeve | 1" Hose ID | Hose OD Range: from 1-37/64" to 1-40/64" | Carbon Steel

Save $2.77 Save $2.77
$6.92
$6.92 - $6.92
$6.92
$4.15
$4.15 - $4.15
$4.15

Dixon Valve
Short Crimp Sleeve

For use with King combination nipples only.

A reliable alternative to band clamps.
Specifications for Variant SKU: CSS100-7CS Dixon
Material(s): Carbon Steel
Material:
  • Carbon Steel
Safety Notes:
  • Not for use with Dixon® King Crimp® Style shanks.
Carbon Steel
Part Number		 Hose I.D. Hose O.D. Sleeve
I.D.		 Sleeve
Wall Thickness		 Sleeve
Overall Length
From To
CSS075-3CS 3/4" 1-5/64" 1-8/64" 1.1875" 0.060" 1-1/4"
CSS075-4CS 3/4" 1-9/64" 1-12/64" 1.250" 0.060" 1-1/4"
CSS075-6CS 3/4" 1-17/64" 1-20/64" 1.375" 0.060" 1-1/4"
CSS075-3CS 1" 1-21/64" 1-24/64" 1.438" 0.060" 1-1/2"
CSS100-4CS 1" 1-25/64" 1-28/64" 1.500" 0.060" 1-1/2"
CSS100-5CS 1" 1-29/64" 1-32/64" 1.563" 0.060" 1-1/2"
CSS100-6CS 1" 1-33/64" 1-36/64" 1.625" 0.060" 1-1/2"
CSS100-7CS 1" 1-37/64" 1-40/64" 1.688" 0.060" 1-1/2"
CSS100-8CS 1" 1-41/64" 1-44/64" 1.750" 0.060" 1-1/2"
CSS150-1CS 1-1/2" 1-41/64" 1-44/64" 1.750" 0.060" 1-3/4"
CSS150-2CS 1-1/2" 1-45/64" 1-48/64" 1.813" 0.060" 1-3/4"
CSS150-3CS 1-1/2" 1-49/64" 1-52/64" 1.875" 0.060" 1-3/4"
CSS150-4CS 1-1/2" 1-53/64" 1-56/64" 1.938" 0.060" 1-3/4"
CSS150-5CS 1-1/2" 1-57/64" 1-60/64" 2.000" 0.060" 1-3/4"
CSS150-6CS 1-1/2" 1-61/64" 2" 2.063" 0.060" 1-3/4"
CSS150-7CS 1-1/2" 2-1/64" 2-4/64" 2.125" 0.060" 1-3/4"
CSS150-8CS 1-1/2" 2-5/64" 2-8/64" 2.188" 0.060" 1-3/4"
CSS150-9CS 1-1/2" 2-9/64" 2-12/64" 2.250" 0.060" 1-3/4"
CSS200-3CS 2" 2-21/64" 2-24/64" 2.438" 0.060" 2"
CSS200-4CS 2" 2-25/64" 2-28/64" 2.500" 0.060" 2"
CSS200-5CS 2" 2-29/64" 2-32/64" 2.563" 0.060" 2"
CSS200-6CS 2" 2-33/64" 2-36/64" 2.625" 0.060" 2"
CSS200-7CS 2" 2-37/64" 2-40/64" 2.688" 0.060" 2"
CSS200-8CS 2" 2-41/64" 2-44/64" 2.750" 0.060" 2"
CSS200-9CS 2" 2-45/64" 2-48/64" 2.813" 0.060" 2"
CSS200-10CS 2" 2-49/64" 2-52/64" 2.875" 0.060" 2"
CSS200-11CS 2" 2-53/64" 2-56/64" 2.938" 0.060" 2"
CSS200-12CS 2" 2-57/64" 2-60/64" 3.000" 0.060" 2"
CSS300-1CS 3" 3-13/64" 3-16/64" 3.313" 0.090" 2-5/8"
CSS300-2CS 3" 3-17/64" 3-20/64" 3.375" 0.090" 2-5/8"
CSS300-3CS 3" 3-21/64" 3-24/64" 3.438" 0.090" 2-5/8"
CSS300-4CS 3" 3-25/64" 3-28/64" 3.500" 0.090" 2-5/8"
CSS300-5CS 3" 3-29/64" 3-32/64" 3.563" 0.090" 2-5/8"
CSS300-6CS 3" 3-33/64" 3-36/64" 3.625" 0.090" 2-5/8"
CSS300-7CS 3" 3-37/64" 3-40/64" 3.688" 0.090" 2-5/8"
CSS300-8CS 3" 3-41/64" 3-44/64" 3.750" 0.090" 2-5/8"
CSS300-9CS 3" 3-45/64" 3-48/64" 3.813" 0.090" 2-5/8"
CSS300-10CS 3" 3-49/64" 3-52/64" 3.875" 0.090" 2-5/8"
CSS300-11CS 3" 3-53/64" 3-56/64" 3.938" 0.090" 2-5/8"
CSS300-12CS 3" 3-57/64" 3-60/64" 4.000" 0.090" 2-5/8"
CSS400-5CS 4" 4-29/64" 4-32/64" 4.563" 0.090" 3-15/32"
CSS400-6CS 4" 4-33/64" 4-36/64" 4.625" 0.090" 3-15/32"
CSS400-7CS 4" 4-37/64" 4-40/64" 4.688" 0.090" 3-15/32"
CSS400-8CS 4" 4-41/64" 4-44/64" 4.750" 0.090" 3-15/32"
CSS400-9CS 4" 4-45/64" 4-48/64" 4.813" 0.090" 3-15/32"
CSS400-11CS 4" 4-53/64" 4-56/64" 4.938" 0.090" 3-15/32"
CSS400-12CS 4" 4-57/64" 4-60/64" 5.000" 0.090" 3-15/32"
