DDA400AL164TTMA by Dixon Valve | MannTek Dry Disconnect Adapter | Tank Unit | 4" TTMA Flange | 164mm Body Size | Aluminum

DDA400AL164TTMA by Dixon Valve | MannTek Dry Disconnect Adapter | Tank Unit | 4" TTMA Flange | 164mm Body Size | Aluminum

Save $105.52 Save $105.52
$949.67
$949.67 - $949.67
$949.67
$844.15
$844.15 - $844.15
$844.15

Dixon Valve
MannTek Dry Disconnect | Tank Unit | Adapter x TTMA Flange

Dry disconnect couplings are designed for the quick and spill free connection and disconnection of hoses and pipelines.

They are used by producers of ink, adhesives, fatty acids, pharmaceuticals, liquid soaps, petroleum, chemicals, agricultural and a wide variety of common caustic and specialty acids.
Specifications for Variant SKU: DDA400AL164TTMA Dixon
Brand: MannTek
Shape (Orientation): Straight
Ends Configuration: 164mm Male Manntek Dry Disconnect, 4in TTMA Flange
Material(s): Aluminum
Seal Material(s): Viton/FKM
Compatibility & Interchange Data:
  • Compatible with Mann-Tek, Avery Hardoll and Todo-matic® and any other product produced according to NATO standard STANAG 3756.
Construction:
  • Standard seal supplied: FKM (FPM).
  • Aluminum poppet.
  • Stainless steel internal parts.
Features:
  • Adapter is usually installed on the tank or manifold.
  • Conical valve seat reduces the risk for piston blow out.
  • PTFE bearing between the piston shaft and the piston guide eliminate the risk for seizure.
  • Easy to handle - push and turn - free flow, turn and pull - closed.
  • Time saving - no need to drain hoses or pipe systems.
  • Economical - no loss or spillage of liquids at connection or disconnection.
  • Safety - the valve cannot be opened until the unit is coupled.
  • Environmental friendly - accidental spillage eliminated when properly used.
  • Safe and reliable - due to rugged construction.
  • Product life - uncomplicated design and high quality materials ensures long product life.
Specifications:
  • Produced according to NATO standard STANAG 3756 and ATOFINA SGM 2049.TUY.C.
  • Working pressure is based on PSI at ambient temperature 70°F.
    • Aluminum: 230 PSI, up to 4"
Use:
  • Use with composite (Polyeten PE-HD 300) caps for protection against corrosion; caps withstand hot and cold environments.
Aluminum
Part Number		 TTMA Flange Body Size
DDA300AL105TTMA 3" 105mm
DDA300AL119TTMA 3" 119mm
DDA400AL164TTMA 4" 164mm
