DVF-A40GA Dixon Valve KF Bored Ferrule (Flange) for D-TORR Vacuum Fitting - Flange Size: KF40 - 304 Stainless Steel

Name: DVF-A40GA Dixon Valve KF Bored Ferrule (Flange) for D-TORR Vacuum Fitting - Flange Size: KF40 - 304 Stainless Steel
Brand: Dixon
SKU: DVF-A40GA Dixon
Price: 12.15 USD
Availability: InStock

Save $8.10

$20.25

$20.25 - $20.25

$20.25

$12.15

$12.15 - $12.15

$12.15

Dixon Sanitary Fittings D-TORR Series Vacuum Fittings: KF Bored Flange - 304 Stainless Steel

Vacuum sealing for 1/2"- 2" OD tubing in the semiconductor industry

Specifications for Variant SKU: DVF-A40GA Dixon
Shape (Orientation):	No Orientation
Material(s):	304 Stainless Steel

Features:
KF assemblies contain two identical flanges and a centering ring assembly and are clamped together with a thumbscrew clamp. Coupling features prevent O-ring collapse and keep the assembly aligned. KF flanges are compatible with other ISO-KF-QF vacuum flange manufacturers' components All fittings are IPA cleaned and bagged in a controlled environment
Materials:
304 Stainless Steel
Specifications:
Maximum temperature: 302°F (150°C) Helium leakage testing to 1x10-8 Torr Standards followed: ISO2681

Part Number	Flange Size	Dimensions
Part Number	Flange Size	A	B	C	D
DVF-A10GA	KF10	0.51"	0.45"	1.18"	0.12"
DVF-A16GA	KF16	0.76"	0.68"	1.18"	0.11"
DVF-A25GA	KF25	1.01"	0.94"	1.58"	0.13"
DVF-A40GA	KF40	1.51"	1.43"	2.17"	0.12"
DVF-A50GA	KF50	2.01"	1.94"	2.95"	0.12"
