FBVG25 by Dixon Valve | Global Ball Valve | Full Port | 1/4" Female NPT x 1/4" Female NPT | Forged Brass

FBVG25 by Dixon Valve | Global Ball Valve | Full Port | 1/4" Female NPT x 1/4" Female NPT | Forged Brass

Save $2.24 Save $2.24
$6.89
$6.89 - $6.89
$6.89
$4.65
$4.65 - $4.65
$4.65

Dixon Valve & Coupling
Global Ball Valve | Forged Brass

For water and air only.
Specifications for Variant SKU: FBVG25 Dixon
Shape (Orientation): Straight
Ends Configuration: 1/4in Female NPT, 1/4in Female NPT, Some Ends Match
Material(s): Forged Brass
Materials:
  • Body: Forged Brass
Specifications:
  • Pressure ratings:
    - 1/4" - 3/8" rated to 365 PSI
    - 1/2" - 2" rated to 600 PSI
  • Maximum temperature: 248°F (120°C)
Part Number Female NPT x Female NPT Port
FBVG25 1/4" Full
FBVG38 3/8" Full
FBVG50 1/2" Full
FBVG75 3/4" Full
FBVG100 1" Full
FBVG125 1-1/4" Full
FBVG150 1-1/2" Full
FBVG200 2" Full
Dixon Valve & Coupling

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
