GL300FG FlutterGuard™ by Dixon Valve | Dry Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-15 PSI Range | ABS Plastic

Save $14.90

$37.25

$37.25 - $37.25

$37.25

$22.35

$22.35 - $22.35

$22.35

Dixon Valve
Dixon® Gauge | FlutterGuard™ | Dry Gauge | Lower Mount

FlutterGuard virtually eliminates pointer flutter, making the gauge easier to read and reducing excessive movement wear, liquid-free casing results in lighter weight and eliminates the chance of gauge leakage.

Specifications for Variant SKU: GL300FG Dixon
Brand:	FlutterGuard
Series:	GL-FG

Features:
ASME B40.1, Grade B (± 3-2-3% accuracy). PowerFlex™ movement with polyester segment, designed to resist the effects of shock, vibration, and pulsation.
Materials:
Window: poly carbonate Pointer: black aluminum Case: ABS plastic, corrosion resistant
Specifications:
Ambient temperature range of -40°F to 150°F (-40°C to 66°C) C-shaped bronze safety bourdon tube (600 PSI gauges and lower) Helical wound bronze safety bourdon tube (1,000 PSI gauges and higher)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

2-1/2" Face 1/4" Lower Mount Part Number	PSI Range	Figure Interval	Minor Gradient
GL300FG	0-15 PSI	1	0.5
GL320FG	0-30 PSI	5	0.5
GL325FG	0-60 PSI	5	1
GL330FG	0-100 PSI	10	2
GL335FG	0-160 PSI	20	5
GL340FG	0-200 PSI	20	5
GL345FG	0-300 PSI	30	5
GL347FG	0-400 PSI	50	10
GL350FG	0-600 PSI	50	10
GL355FG	0-1000 PSI	200	20
GL360FG	0-1500 PSI	300	50
GL365FG	0-2000 PSI	400	50
GL370FG	0-3000 PSI	500	100
GL375FG	0-5000 PSI	1000	100
