GLSS300 by Dixon Valve | Liquid Filled Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-300 PSI Range | Stainless Steel

$42.65 - $42.65

$42.65

$44.08

$44.08 - $44.08

$44.08

Dixon Valve
Dixon® Gauge | Liquid Filled Gauge | Lower Mount

Designed for severe service applications, providing the corrosion resistance and durability of a permanently sealed gauge.

Quantity

Specifications for Variant SKU: GLSS300 Dixon
Series:	GLSS Series

Features:
± 2-1-2% accuracy. 1/4" NPT lower mount stainless connector.
Materials:
Window: poly carbonate Case and crimp ring: 304 stainless Glycerin filled
Specifications:
Ambient temperature range: 20°F to 158°F (-7°C to 70°C)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

2-1/2" Face 1/4" Lower Mount Part Number	PSI Range	Figure Interval	Minor Gradient
GLSS15	0-15 PSI	3	0.2
GLSS30	0-30 PSI	5	0.5
GLSS60	0-60 PSI	10	1
GLSS100	0-100 PSI	20	2
GLSS160	0-160 PSI	20	2
GLSS200	0-200 PSI	50	5
GLSS300	0-300 PSI	50	5
GLSS400	0-400 PSI	100	10
GLSS600	0-600 PSI	100	10
GLSS1000	0-1000 PSI	200	20
GLSS1500	0-1500 PSI	300	20
GLSS2000	0-2000 PSI	500	50
GLSS3000	0-3000 PSI	500	50
GLSS5000	0-5000 PSI	1000	100
GLSS10000	0-10000 PSI	2000	200

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
